60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
Specifications
Brand Name :
NUOYINGJIAYE
Model Number :
WSS Series
Certification :
CE
Place of Origin :
Xi'an,China
MOQ :
5pcs
Price :
$25.0~$110.0
Payment Terms :
T/T
Supply Ability :
1000pcs/pre month
Packaging Details :
40*30*30cm Carton
Material :
SS 304
Measuring range :
0-150ºC
Accuracy class :
1.5
Window :
Glass
Response time :
≤40s
Dial size :
60mm
Connection :
Thread
Waranty :
One year
Description

Stainless Bimetal Thermometer Temperature Gauge

Stainless Bimetal Thermometer Temperature Gauge Description:

Bimetallic thermometer is a kind of on-site measuring instrument for measuring medium and low temperature. It can directly measure the temperature of liquid vapor and gas medium in the range of -80°C-+500°C in various production processes. The main component of an industrial bimetallic thermometer is a multi-layer metal sheet consisting of two or more metal sheets laminated together, using the principle that two different metals expand differently when the temperature changes. It is based on a bimetallic strip wound into a loop shape. When one end is heated to expand, the pointer is rotated, and the working instrument shows the temperature value of the thermoelectric potential.

Stainless Bimetal Thermometer Temperature Gauge Features:

Wide voltage power supply, non-linear correction, high accuracy
Small size, light weight, easy to install
Lightning, cutoff frequency interference design, anti-interference ability
Wiring reverse and overvoltage protection, current limiting protection

Suitable for indoor plumbing or cavities within the body temperature measurement, non-hazardous general scene.

Stainless Bimetal Thermometer Temperature Gauge Technical Parameters:

Back Install Bimetallic thermometer

Model Temperature range ℃ Accuracy Protection tube material Specifications Install
D L
WSS-300

-80-+40

0-80

0-100

0-150

0-200

0-400

0-500

　

 1．0

1Cr18Ni9Ti

304

316

316L

HastelloyC-276

 Φ60

75

100

150

200

300

400

500

750

1000

　

 No
WSS-400 Φ100
WSS-500 Φ150
WSS-301 Φ60 Movable external thread
WSS-401 Φ100
WSS-501 Φ150
WSS-302 Φ60 Movable internal thread
WSS-402 Φ100
WSS-502 Φ150
WSS-303 Φ60 Fixed thread
WSS-403 Φ100
WSS-503 Φ150
WSS-304 Φ60 Fixed flange
WSS-404 Φ100
WSS-504 Φ150
WSS-305 Φ60 Ferrule thread
WSS-405 Φ100
WSS-505 Φ150
WSS-306 Φ60 Ferrule flange
WSS-406 Φ100
WSS-506 Φ150

Bottom Install Bimetallic thermometer

Model Temperature range℃ Accuracy Protection tube material Specifications(mm) Install
D L
WSS-310

-80-+40

0-80

0-100

0-150

0-200

0-400

0-500

　

 1．0

1Cr18Ni9Ti

304

316

316L

HastelloyC-276

 Φ60

75

1 00

150

200

300

400

500

750

1000

　

 No
WSS-410 Φ100
WSS-510 Φ150
WSS-311 Φ60 Movable external thread
WSS-411 Φ100
WSS-511 Φ150
WSS-312 Φ60 Movable internal thread
WSS-412 Φ100
WSS-512 Φ150
WSS-313 Φ60 Fixed thread
WSS-413 Φ100
WSS-513 Φ150
WSS-314 Φ60 Fixed flange
WSS-414 Φ100
WSS-514 Φ150
WSS-315 Φ60 Ferrule thread
WSS-415 Φ100
WSS-515 Φ150
WSS-316 Φ60 Ferrule flange
WSS-416 Φ100
WSS-516 Φ150

135 angle Install Bimetallic thermometer

Model Temperature range℃ Accuracy Protection tube material Specifications(mm) Install
D L
WSS-420

-80-+40

0-80

0-100

0-150

0-200

0-400

0-500

　

 1．0

1Cr18Ni9Ti

304

316

316L

HastelloyC-276

　

 Φ100

75

100

150

200

300

400

500

750

1000

　

 No
WSS-520 Φ150
WSS-421 Φ100 Movable external thread
WSS-521 Φ150
WSS-422 Φ100 Movable internal thread
WSS-522 Φ150
WSS-423 Φ100 Fixed thread
WSS-523 Φ150
WSS-424 Φ100 Fixed flange
WSS-524 Φ150
WSS-425 Φ100 Ferrule thread
WSS-525 Φ150
WSS-426 Φ100 Ferrule flange
WSS-526 Φ150

Universal type Bimetallic thermometer

Model Temperature range℃ Accuracy Protection tube material Specifications Install
D L
WSS-480

-80-+40

0-80

0-100

0-150

0-200

0-400

0-500

　

 1．0

1Cr18Ni9Ti

304

316

316L

HastelloyC-276

　

 Φ100

75

100

150

200

300

400

500

750

1000

　

 No
WSS-580 Φ150
WSS-481 Φ100 Movable external thread
WSS-581 Φ150
WSS-482 Φ100 Movable internal thread
WSS-582 Φ150
WSS-483 Φ100 Fixed thread
WSS-583 Φ150
WSS-484 Φ100 Fixed flange
WSS-584 Φ150
WSS-4285 Φ100 Ferrule thread
WSS-585 Φ150
WSS-486 Φ100 Ferrule flange
WSS-586 Φ150
Stainless Bimetal Thermometer Temperature Gauge Technical Dimensions:

60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree60mm Dial Bimetal Temperature Gauge 1.5 Accuracy SS304 0-150 Degree
