High Precision Shark Fin Car Aerial , Passive TV Antenna M8 Screw Thread Installation
High Precision Shark Fin Car Aerial , Passive TV Antenna M8 Screw Thread Installation
High Precision Shark Fin Car Aerial , Passive TV Antenna M8 Screw Thread Installation
High Precision Shark Fin Car Aerial , Passive TV Antenna M8 Screw Thread Installation
Specifications
Brand Name :
CAZAN
Model Number :
CAT-3008
Certification :
CE,ROHS
Place of Origin :
CHINA
MOQ :
500pcs
Price :
negotiation
Payment Terms :
T/T, L/C
Supply Ability :
16000pcs/ each month
Delivery Time :
16--28 WORK DAYS
Packaging Details :
polybag or blister packing etc
function :
dab,am fm
V.S.W.R :
≤2.0:1
Voltage :
DC10-14V
Installation :
M8 screw thread
connector type :
SMA male etc
gain :
20dbi
Description

high quality am/fm radio DAB car antenna active shark fin antennae

ITEM NO.: CAT-3008

Product Description

DAB ANTENNA Specification

DAB Antenna Working Frequency: 170MHz~240MHz (Band III)
1452MHz~1492MHz (L-Band)
Output Gain: 15dB±3dB (Band Ⅲ)
12dB±3Db (L-Band)
Output impedance: 75Ω
V.S.W.R: ≤2.0:1
NOISE Figure: ≤2dB
Working current: 30mA~60mA
Rated voltage: DC 12V
Rated Current: 40mA~50mA
AM FM Antenna Frequency: 76-110MHz (FM), 525-1,700MHz (AM)
Gain: +20dB (FM), +5dB (AM)
Impedance: 75 ohm
Cable: 3C-2V
Voltage: 10-14V
Mechanical Weight(gram)<240
Size(mm): 65*78*148
Cable: 2,3 etc.
Connector: SMA,etc
Mounting:Screw
Housing:Black
Environmental Working Temp:-40℃~+85℃
Storage Temp:-45℃~+85℃
Vibration:Sine sweep1g(0-p)10~50~10Hz each axis
Humidity:Humidity95%~100%RH
Weatherproof:100%Waterproof(IP67)

We use are all new plastic, can resist ultraviolet ray and aging resistance, increase the service life of the antenna.Product is beautiful and clean without burr,.If you install the antenna, will make your car is very beautiful.

Quality assurance:

Warranty Duration: 1 years
Warranty Type: Manufacturer Warranty

Our Company
CAZAN Electronics has over 8 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.
Our manufacturing facilities can build just about many types of custom car AM/FM antenna, GPS,GSM antenna, TV antenna, DAB antenna ,CB antenna etc.

Our advantages:


1. Quality control:most of products have CE ROHS, certificate. ISO9001:2008.
2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.
3. Fast Delivery Time :3~20 days, On-Time Delivery.
4. Good After-Sales Service: we could offer technical support or return service in short time.
5. 1 Year Warranty.
6. OEM/ODM service.


We can give you a promise:


•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount

Product details

High Precision Shark Fin Car Aerial , Passive TV Antenna M8 Screw Thread Installation

High Precision Shark Fin Car Aerial , Passive TV Antenna M8 Screw Thread Installation
