Round 125 Khz Dry Rfid Inlay Copper Antenna 0.35-0.60MM Thickness For LF Tag​
Round 125 Khz Dry Rfid Inlay Copper Antenna 0.35-0.60MM Thickness For LF Tag​
Round 125 Khz Dry Rfid Inlay Copper Antenna 0.35-0.60MM Thickness For LF Tag​
Round 125 Khz Dry Rfid Inlay Copper Antenna 0.35-0.60MM Thickness For LF Tag​
Specifications
Brand Name :
A.N.G
Model Number :
AT-SI113
Certification :
CE,ISO,ROHS
Place of Origin :
Shenzhen, CHINA
MOQ :
500pcs
Payment Terms :
T/T, Paypal, Western Union, MoneyGram
Supply Ability :
5,000,000pcs per month
Delivery Time :
7-15 days
Packaging Details :
According to different customer choice
Price :
Depends on chips
Item Type :
LF 125KHZ Dry Inlay
Operation Frequency :
125KHz
Dimension :
22mm
Material :
copper
Reading range :
About 1~3cm (vary from different reader and environment)
Chip :
EM, T5577, etc…
Description

Round 125 Khz Dry Rfid Inlay Copper Antenna 0.35-0.60MM Thickness For LF Tag​

Thickness of LF RFID Inlay can be 0.35~0.60mm. Inside of the inlay ,we adopt etched antenna or ultrasonic automatic submerged line coil for production process, internal coil arrangement can be arranged in accordance with customer requirements. In the inlay we can print date, logo, etc…according to customers' requirements. On the surface it can be printed wireframe, outside of inlay can be cut into any size according to customer’s requirements.

Description:

1. Chip: EM, TK, T5577, etc…

2. Frequency: 125KHz

3. User memory :128 / 512 / 1536 / 1k bit,320 / 1k/ 2k/ 4k/ 8k byte

4. Protocol Standard: ISO 11785

5. LF Read range:0-5cm (Related to the chip ,antenna and reader)

6. Read/Write Endurance: 100,000 times

7. Operating Temperature :-20°C to + 55°C

Brand Name

A.N.G

Material

copper

Dimension

22mm

Item Type

LF 125KHz Inlay

Endurance

100,000 times

Color

White, blank

Chip

EM, TK, T5577, etc…

Product feature:

Material: copper

Dimension: 22mm

Color: white, blank

Depends on requirement

Applications:

1. Goods and device authentication

2. Voucher and coupons

3. Product authentication

4. Mobile companion tags

5. Electronic shelf labels

Round 125 Khz Dry Rfid Inlay Copper Antenna 0.35-0.60MM Thickness For LF Tag​

If you are interested in this inlay, please welcome to send us an inquiry!
