Long Range RFID Tag Card Printable Ultralight EV1 Tag for Access Control
Long Range RFID Tag Card Printable Ultralight EV1 Tag for Access Control
Long Range RFID Tag Card Printable Ultralight EV1 Tag for Access Control
Long Range RFID Tag Card Printable Ultralight EV1 Tag for Access Control
Long Range RFID Tag Card Printable Ultralight EV1 Tag for Access Control
Long Range RFID Tag Card Printable Ultralight EV1 Tag for Access Control
Specifications
Brand Name :
A.N.G
Model Number :
AT-SH152
Certification :
CE,ISO,ROHS
Place of Origin :
Shenzhen, CHINA
MOQ :
500pcs
Price :
Depending on the chip, material, printing
Payment Terms :
T/T,Paypal,Western Union, MoneyGram
Supply Ability :
5,000,000pcs per month
Delivery Time :
7-15 days
Packaging Details :
1000pcs / tie
Keywords :
rfid sticker, rfid tag, HF label
Chip: :
MF Ultralight ® EV1
Material: :
PVC, PET, PAPER
Size: :
56*18MM
RF interface: :
ISO/IEC 14443 Type A
Fast data transfer: :
106 kbit/s, 212 kbit/s, 424 kbit/s, 848 kbit/s
Description

Long Range RFID Tag Card Printable Ultralight EV1 Tag for Access Control

MF EV1 4K Stickers Tag. With their high memory capacity and the option to increase security these tags are popular for NFC applicatons that require extra security such as micro payments, loyalty programmes and access management.

The stickers size are 56*18mm. Stickers are supplied either individually, as folded strip or on a reel depending on quantity ordered.

Specifications:

Antenna Material Aluminum Al (30μm) + PET (38μm) + Al bridge (10μm)
Chip MF Ultralight ® (512bits)
Frequency 13.56 MHz
RF Protocol ISO14443-A
Fast data transfer: 106 kbit/s, 212 kbit/s, 424 kbit/s, 848 kbit/s
Working life 100000 times / 10 years
Antenna size DIA20m
Wet inlay DIA22/23/25 mm
Thickness 0.07mm (chip location: 0.23mm)
Weight 0.01g
Working temperature -20℃ to +60℃
Storage temperature -25℃ to +65℃
Packing 1000pcs/roll or by customized
Read Distance up to 3.5~5.5cm depending on antenna geometry and reader configuration
Shelf life one year Under the conditions of vacuum packaging,temp 20-30℃/humidity 20%-60%
Application Identification,Card, Logistics, Library, Asset management, Payment, Access control

MF EV1 4K Technical Specifications

  1. Integrated Circuit (IC): MF EV1 4K
  2. Air interface protocol: ISO 14443 A
  3. Operation Frequency: 13.56 MHz
  4. Applications: Retail, Product Authentication, Mobile Payment, Marketing, Advertisements, Social Media, etc.

Aviable Crafts
  • Printing: Offset Printing,Silkscreen Printing,Thermal printing,Ink-jet printing,Digital printing.
  • Security features: Laser ablation,Hologram/OVD,UV ink,Optical Variable ink,Hidden barcode/Barcode mask,Graded Rainbow,Micro-text.
  • Others: Signature panel,Barcode,Serial number,Embossing,Encoding,Die-cut.

Target Applications

  • Public transport ticketing: Account based or Single Journey ticketing
  • High secure access management
  • Hospitality
  • Event ticketing
  • Loyalty
  • Gift cards
  • Smart Visitor Badges (SVB)

Long Range RFID Tag Card Printable Ultralight EV1 Tag for Access Control

If you are interested in this tag, please welcome to send us an inquiry!
