170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
170T Railway Ladle Transfer Carts for Molten Steel Transportation
Specifications
Brand Name :
Kingrail
Model Number :
170T
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1
Price :
1000-100000
Payment Terms :
L/C, T/T
Supply Ability :
50PCS/MONTH
Delivery Time :
10-80 WORKING DAYS
Packaging Details :
standard export PACKAGE
Track Gauge :
1435mm,1067mm,1000mm、762mm、600mm,1524mm、1520mm
load :
50 ton,60 ton,70 ton
speed :
less than 120 km/h
Bogie Type :
Welded Bogie
Description

The KR-170 series molten steel transport car we produce is specially designed for transporting blast furnace hot molten iron (pig iron) ladles to converters, electric furnaces and other steelmaking equipment by rail.

The KR series ladle transfer car has the characteristics of simple structure, small size, low cost, small transportation radius, and convenient maintenance and operation. It can reach the standard of JB/T.

Specifications:

ModelTanker loading capacity (t)Rail Gauge(mm)Center distance of bogies(mm)Inner distance between two coupler knuckle(mm)Coupler center height(mm)Min radius(m)Dimension(length×width×width)(mm)
ZT-35-135143537006722880506722×3120×2720
ZT-65-165143541608310880608310×3580×3679
ZT-65-265143541007142880607142×3580×3420
ZT-100-1100143542008310880758310×3600×4210
ZT-140-11401435538096608801009660×3700×4550
ZT-140-2140143550009000880759000×3610×4500
ZT-170-1170143573001480088010014800×3700×4900


Features:
1. Durable and reliable structure
2. Low speed
3. Small radius
4. Easy operation and maintenance
5. Safety

Get more information
Please contact us for more information and quotation.
