High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
Specifications
Brand Name :
HTR
Place of Origin :
CHINA
MOQ :
1000
Price :
Ngotiable
Payment Terms :
L/C, T/T
Supply Ability :
50000 pcs per month
Delivery Time :
Ngotiable
Packaging Details :
Export packaging
Product name :
Composite Sleepers
Material :
Composite
Electrical resistance :
> 150 kΩ
Density :
~ 1.55 g/cm3
Fire behaviour :
Difficult to ignite, low smoke development
Modulus of elasticity :
2.300 - 7.300 MPa
Description
Fields of application Direct fastening Indirect fastening Turnout sleepers Bridge beams
Axle loads up to 35.5 t up to 35.5 t up to 25 t up to 25 t
Electrical resistance > 150 kΩ > 150 kΩ > 150 kΩ > 150 kΩ
Density ~ 1.55 g/cm3 ~ 1.55 g/cm3 ~ 1.55 g/cm3 ~ 1.55 g/cm3
Coefficient of thermal expansion 19,8 x 10-6 1/K 17,5 x 10-6 1/K 17,5 x 10-6 1/K 23,9 x 10-6 1/K
Modulus of elasticity 2.300-7.300 MPa 2.300-7.300 MPa 2.300-7.300 MPa up to 8.500 MPa
Anchoring pull-out forces for standard sleeper screws > 85 kN > 70 kN
(drilled screw hole)		 > 70 kN
(drilled screw hole)		 > 70 kN
(drilled screw hole)
> 85 kN
> 85 kN (prefabricated screw hole) (prefabricated screw hole)
Water absorption ~ 0.1% ~ 0.1% ~ 0.1% ~ 0.1%
Fire behaviour Difficult to ignite, low smoke development
Dimensions[mm] 160 x 260 x 2.600 150 x 250 x 2.600 160 x 260 x 2.600 150 x 250 x 2.600 160 x 260 x 2.200-5.000
150 x 250 x 2.200-5.000		 Basic bridge beam 160 x 240 x 2,600 Height adjustment elements up to 160 mm Total height from 160 up to 320
Weight 170 kg 175 kg 74 kg/m 170 - 200 kg

High Performance Rail Road Ties Eco-friendly Railway Composite Sleeper

Develop a composite sleeper that combines the best properties of wooden, concrete, Environmental considerations are also playing an increasingly important role in the development of railway sleepers. Our responsibility as a leading developer of railway infrastructure components must therefore be to extend the range of products we offer by an especially eco-friendly and resource-saving alternative to traditional solutions. and plastic sleepers.To use polymer, filler sand and additives to create a completely new and innovative material that can withstand even the most

extreme climatic conditions.
Advantage:
1.Designed for various axle loads
2.Customized dimensions & stiffnesses possible
3.Individual design and moulding
4.High weather resistance
5.Unlike wooden sleepers, no impregnation necessary
6.Sleeper stiffness adjustable due to rebar and material mix

High Performance Rail Road Ties Eco-friendly Railway Composite SleeperHigh Performance Rail Road Ties Eco-friendly Railway Composite SleeperHigh Performance Rail Road Ties Eco-friendly Railway Composite Sleeper
