Specifications
Brand Name :
HAROK
Model Number :
HB2 series
Certification :
CE
MOQ :
3000
Description

Push Button HB2 series

HB2series push button switch are used in industrial control of AC 50HZ or 60HZ,rated operational voltage 380V and below and DC operational voltage 220V and below for controlling in magnetic starter,contactor,relay and other electrical circuits. The buttons with indicator,The products confirm with the standard GB14048.5-2001.

10A 660V Pilot Indicator Light Led Indicator Push Button Switch10A 660V Pilot Indicator Light Led Indicator Push Button Switch

10A 660V Pilot Indicator Light Led Indicator Push Button Switch

Main technical parameters

Operational temperature: -5℃~+40℃ power-frequency withstand voltage: 2500V
Operational humidity: 45%~85% Electrical durability: 50x104
Operational resistance: ≤50mΩ Degree of protection: IP40
Rated Insulation voltage Ui 660V
Conventional thermal current 10A
Rate operational voltage Ue 380V 220V 110V 48V 24V
Rated operatlonal currentle AC-15 2.5A 4.5A 6A 8A -
DC-13 - 0.3A 0.6A 1.3A 2.5A

Rate voltage

Lanp-house

 Directness Resistance Transformer
6V 12V 24V 48V 110V 220V 380V 220V 220V 380V
LED led1amp ✓ ✓ / - - - - - / ✓
Neon lamp - - - - ✓ ✓ ✓ ✓ - -
Lncandescence lamp ✓ V ✓ ✓ ✓ ✓ ✓ - ✓ ✓
