100m Depth Crawler Hydraulic Solar Pile Driver Both Rotary Drilling And Ramming

Product Description

The RC260Y hydraulic solar pile hammer is an advanced equipment specially designed for the construction of photovoltaic power stations. What is unique from traditional pile hammers is that it uses imported original accessories to ensure optimal performance and stability. Its construction technology and climbing mechanism design allow for flexible adjustment according to slope height, making it excellent in the construction of photovoltaic projects with slopes up to 45 degrees. The pile hammer can be flexibly used in various photovoltaic construction technologies, including helical pile drilling, helical hole drilling, rock DTH hammer and pile driving, etc., and can cover boreholes with diameters ranging from 100 - 400 mm and depths of 20 - 100 meters.

In addition to its advantages of high efficiency, wide application and excellent stability, RC260Y ’ s biggest differentiating feature is its powerful hydraulic system, which can quickly install a large number of solar panels and remain stable and stable even on slopes and uneven ground. In addition, its simple design, convenient operation and low maintenance cost ensure the continuous and efficient operation of the equipment, making it an indispensable tool in the construction of photovoltaic power stations.

Product Specifications

Product Features

1,Engine: 88KW turbocharged engine ,Yuchai famous brand,very powerful engine.

2,Walking device: equipped with new walking motor and reducer, with long service life.

3,Hydraulic oil pump: PERMCO ,imported from the United States, the parallel gearbox is designed to separate the oil pump, providing sufficient and reasonable power distribution. The unique design of the advanced hydraulic system, simple maintenance and low cost.

4,Power head device of this PV solar pile driver:America Eaton ,imported brand ,The gearbox body is made of one body, the twin motors provide more power, more torque, more durable, less maintenance cost.

5,hydraulic system of this solar piling rig :Italy Hydrocontrol hydraulic valve and hydraulic system ,stable performance ,less maintenance and comfortable operation.

6,Drilling rig chassis; Professional excavator chassis, classic durable, large weight bearing, wide chain plate width, small damage to hard pavement.

7,this hydraulic solar piling machine has compact structure, and the mast has telescopic compensation function, during working the mast are supported on the ground, it has high borehole stability .

8,this ground screw piling machine has reliable performance, high efficiency, multifunctional applications.

9,The screwing and ramming power heads can be interchanged to adapt to different engineering construction technologies, which is more adaptable and more comprehensive for solar ground mounting , can save more cost for customers.

Product Image
