Isuzu Engine Powered Container Lifting Forklift 1.5 Ton Load Capacity Eco Friendly Design
Isuzu Engine Powered Container Lifting Forklift 1.5 Ton Load Capacity Eco Friendly Design
Specifications
Brand Name :
JAC
Model Number :
CPCD15
Certification :
CE,ISO9001,ISO14001,OHSAS18001
Place of Origin :
CHINA
MOQ :
1UNIT
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000UNITS/Month
Delivery Time :
25 working days
Load Capacity :
1500KG
Warranty :
One Year
Power :
Diesel
Color :
Orange
Lift height :
3m to 6m
Engine brand :
Isuzu or Xinchang
Min Turning Radius :
1955 mm
Min Aisle Width :
2155 mm
Description

Isuzu Engine Powered Diesel Forklift , Load Capacity 1.5 Ton , CPCD15H , Optional Chinese Engine

When you work outside with your forklift truck, you may need much power for lifting. Then JAC diesel forklift will be your right choice.
As a China diesel forklift manufacturer, we offer two series of forklift trucks: H series and J series, which are characterized by adjustable steering wheel and seats, as well as rational layout of each operating system, fully embodying the principles of ergonomics and effectively reducing the labor intensity.

1. The eco-friendly design of the diesel forklift offers full protection to both the user and the environment.
2. Small overall dimension,low centre of gravity, small turning radius, and excellent manoeuvrability.
3. The frame and the steering axle of the material handling equipment are engineered with shock absorber to reduce the impact and maximize the comfort during operation.
4. Multiple engines for selection.

Parameters:

Model CPCD15
1 Feture Power Type 　 Diesel
2 Load Capcity kg 1500
3 Load center mm 500
4 Lift height mm 3000
5 Free lift height mm 155
6 Forkk size L*W*H mm 920×100×40
7 Mast tilt FR/RR . 6/12
8 Min turning Radius mm 1955
9 Min Right angle stacking aisle width mm 3365
10 Min right angle aisle width mm 2155
11 Min ground clearance mm 110
12 Height of overhead guard mm 2060
13 Overhang mm 410
14 Performance Max driving speed Full load km/h 14.5
15 Max Lifting speed Full load mm/s 550
16 Max drawbar pull Full load KN 14
17 Gradeabiity % 20
18 Dimension Overall length Without forks mm 2234
19 Over width mm 1080
20 Height mast lifted(with backrest) mm 3930
21 Height mast lowered mm 2010
22 Chassis Tyre Front 　 6.50-10-10PR
23 Rear 　 5.00-8-10PR
24 Wheelbase mm 1400
25 Tread FR/RR mm 891/920
26 Self weight Without load Kg 2790
27 Drive Battery Voltage / Capacity V/Ah 12/80
28 Engine Model 　 XC485BPG
29 Rated Power kw/r.p.m 30/2600
30 Rated Torque Nm/r.p.m 131/1820
31 Bore * sTROKE mm 85×100
32 No.of Cylinder 　 4
33 Displacement L 2.27
34 Fuel tank capacity L 49
35 Transmission 　 1/1manual shift
36 Operating Pressure Mpa 15.5
37 Supplement Tire type (FR/RR) 　 Pneumatic
38 Numbers of wheels pcs 2/2
39 lowering speed (full load) mm/s 430
40 Lowering speed ( unload) mm/s 530
41 Axle load distribution (full load) (FR/RR) kg 3640/520
42 Axle load distribution (unload) (FR/RR) kg 1170/1490

Feartures:

Isuzu Engine Powered Container Lifting Forklift 1.5 Ton Load Capacity Eco Friendly Design Isuzu Engine Powered Container Lifting Forklift 1.5 Ton Load Capacity Eco Friendly Design

Isuzu Engine Powered Container Lifting Forklift 1.5 Ton Load Capacity Eco Friendly Design Isuzu Engine Powered Container Lifting Forklift 1.5 Ton Load Capacity Eco Friendly Design

Isuzu Engine Powered Container Lifting Forklift 1.5 Ton Load Capacity Eco Friendly Design Isuzu Engine Powered Container Lifting Forklift 1.5 Ton Load Capacity Eco Friendly Design
