7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
Specifications
Model Number :
18650 2S1P 7.4V 2000mAh
Certification :
UN38.3, MSDS, IEC62133, RoHS
Place of Origin :
China
MOQ :
500pieces
Payment Terms :
T/T
Supply Ability :
100'000Pieces daily
Delivery Time :
within 15days
Packaging Details :
Bulk packing
Battery Type :
Lithium cylindrical battery pack
Model :
18650 2S1P 7.4V 2000mAh
Nominal Voltage :
7.4V
Nominal Capacity :
2000mAh
End of Charging :
8.4V
Cut-off voltage :
6V
Cycle life :
500times
Certificate :
CB-IEC62133, KC, UN38.3, UL
Description

KC 18650 7.4v 2000 Mah Lithium Ion Battery 7.4wh Lithium Cylindrical Battery

18650 7.4V 2000mAh lithium cylindrical battery pack

No. Item General Parameter Remark
1 Rated Capacity 2000mAh Standard discharge(0.2 C5) after standard charge(0.2 C5)
2 Minimal Rated Capacity 2000mAh
3 Nominal Voltage 7.4V
4 Cycle Life Higher than 60% of the Initial Capacity of the Cells *Charge: CC 0.2C to 4.2V/cell,then CV *till current to 0.05C
*Rest: 30min.
*Discharge: 0.2C to 2.8V/cell
*Temperature:20±5℃
*Carry out 500cycles
5 Discharge cut-off voltage 5.5V 5.5V( recommended)
6 Charging cut-off voltage 8.4V 8.4V (recommended)
7 Cell and assembly method NV-ICR18650-1.8Ah 2S1P
8 Housing material PVC
9 Standard charge 0.2C constant current(CC) charge to 4.2V,then constant voltage(CC) 4.2V charge till charge current decline to ≤0.05C Charge time : Approx7h
10 Standard discharge Constant current 0.2C Cut-off voltage 2.8V
11 Maximum Charge Current 2.5A
12 Continuous Current 2.5A
13 Operation Temperature Range Charge: 0~45℃ 60±25%R.H.
Discharge: -10~60℃
14 Storage Temperature Range Less than 1 year: 0~25℃ 60±25%R.H. at the shipment state
Less than 3 months:-5~35℃
15 Weight Approx/:102g
16 Max.Dimension Thickness/:20mm
Width/: 38mm
Length/: 70mm

Detailed images: 3C discharge rate 18650 Lithium ion batteries 7.4V 2000mAh/3000mAh

Model
Capacity(mAh)
Combination
18500-3.7V
1200-12000
One or more parallel sections can be arranged in size at will
18500-7.4V
1200-12000
Two strings of multi - parallel, can be arranged in a variety of sizes
18500-11.1V
1200-12000
Three strings of multiple, can be arranged in a variety of sizes
18650-3.7V
1200-100000
One or more parallel sections can be arranged in size at will
18650-7.4V
1200-100000
Two strings of multi - parallel, can be arranged in a variety of sizes
18650-11.1V
1200-100000
Three strings of multiple, can be arranged in a variety of sizes
21700-3.7V
4500-45000
One or more parallel sections can be arranged in size at will
21700-7.4V
4500-45000
Two strings of multi - parallel, can be arranged in a variety of sizes
21700-11.1V
4500-45000
Three strings of multiple, can be arranged in a variety of sizes
More model specifications...... More voltage and capacity can be customized
14430 14500 26650 and so on more models and specifications to choose from
3.7V-48V and other high voltage and high capacity combination can be customized
Cylindrical battery model specifications are various, We can't list them at all, welcome to contact customer service to learn more
about model specifications and related certification.

Customized KC UL 18650 Li Ion Rechargeable Battery 7.4 V 2500mah Cylindrical Battery Cell

7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery

Other lithium ion cylindrical battery cell on sale:

Lithium ion battery cells list
Model No. Nominal Voltage Typical Capacity Size Charge Rate Discharging Rate Weight(g)
ICR14500 3.7V 600mah 13.9×48.5±0.3 0.2-1C 0.2-2C 19.5
ICR14500 3.7V 750mah 13.9×48.5±0.3 0.2-1C 0.2-2C 20
ICR14500 3.7V 800mah 13.9×48.5±0.3 0.2-1C 0.2-2C 20.5
ICR18500 3.7V 1300mah 18.0×49.7±0.2 0.2-1C 0.2-2C 32
ICR18500J 3.7V 1400mah 18.0×49.7±0.2 0.2-1C 0.2-2C 31
ICR18500 3.7V 1600mah 18.0×49.7±0.2 0.2-1C 0.2-2C 32
ICR18650 3.7V 2200mah 18.0×65.2±0.2 0.2-1C 0.2-2C 40
ICR18650 3.7V 2600mah 18.0×65.2±0.2 0.2-1C 0.2-2C 45
ICR18650 3.7V 3000mah 18.0×65.2±0.2 0.2-1C 0.2-2C 48
ICR18650 3.7V 3400mah 18.0×65.2±0.2 0.2-1C 0.2-2C 50
ICR26650 3.7V 4500mah 26.3×65.0±0.5 0.2-1C 0.2-2C 80
ICR26650 3.7V 5000mah 26.3×65.0±0.5 0.2-1C 0.2-2C 85
ICR18650P 3.7V 2600mah 18.0×65.2±0.2 0.2-1C 5C 45

Why Choose us:

R&D

Experienced R&D team with over 60 engineers and advanced equipments for supporting OEM and ODM requirements.

7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery

Certificates-CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.

7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery

Factory Tour:

Shenzhen Gold Power Eenergy Co.,Ltd is one of the leading battery suppliers in China.

We have started to offer various batteries including Li polymer battery, Lithium ion battery, LiFePO4 battery,

and customized battery pack since 2001.

7.4wh Lithium Cylindrical Battery , KC 18650 7.4v 2000Mah Lithium Ion Battery
