48V 200Ah Hybrid Residential Battery Backup System High Efficiency
48V 200Ah Hybrid Residential Battery Backup System High Efficiency
48V 200Ah Hybrid Residential Battery Backup System High Efficiency
48V 200Ah Hybrid Residential Battery Backup System High Efficiency
Specifications
Brand Name :
Topband
Model Number :
TB48200F-T110B
Certification :
CE, MSDS, UN38.3
Place of Origin :
China
MOQ :
100
Supply Ability :
450Mwh/year
Delivery Time :
2~4weeks for samples; 4~6weeks for mass production
Packaging Details :
standard export carton
Price :
Negotiable
Payment Terms :
L/C, T/T
Nominal Voltage :
51.2V
Typical Capacity :
200Ah
Material :
LiFePO4
Dimension :
552*400*400mm
Weight :
125Kg
Standard charge current :
60A
Maximum charge current :
100A
Internal resistance :
≤30mΩ
Cycle life （DOD100%） :
1600 cycles
Warranty :
2 years
Description

48V 200Ah Hybrid Residential Battery Backup System High Efficiency

1. General Information

This specification defines the performance of rechargeable LiFePO4 battery pack TB48200F-T110B manufactured by Shenzhen Topband Battery Co., Ltd, describes the type, performance, technical characteristics, warning and caution of the battery pack.

2. Specification

NO. Items Criteria Remarks
2.1 Rated Capacity 200Ah
Minimum Capacity 190Ah
2.2 Energy 10.24KWh
2.3 Nominal Voltage 51.2V
2.4 Outgoing Voltage ≥51.2V
2.5 Internal resistance ≤30mΩ
2.6 Limited charge voltage 58.4±0.2V
2.7 Floating charge voltage 55.2±0.2V
2.8 Standard charge current 60A
2.9 Maximum charge current 100A
2.10 Standard discharge current 100A
2.11 Maximum discharge current 150A/Continuous for 1 hour
2.12 Pulse discharge current 200A/Continuous for 15 min
2.13 Discharge cut-off voltage 40.0V

2.14

 Dimension Length: 552±3mm
Width: 400±3mm
Height: 400±3mm
2.15 Weight Approx: 125±5Kg

2.16

 Operating Temperature Charging:0～45℃
Discharging:-20～60℃
Recommended operating temperature:15℃～35℃
2.17 Self-discharge rate Residual capacity:≤3%/ month;≤15%/years
Reversible capacity: ≤1.5%/ month;≤8%/ years
2.18 Storage Temperature & Humidity Range Less than 1 month:-20℃～35℃,45%RH～75％RH
Less than 3 months:-10℃～35℃,45%RH～75％RH

Recommended storage environment:

15℃～35℃,45%RH～75％RH

Long time storage:

If the battery need be stored for a long time, the voltage should be 52.8V(50%SOC), and stored in the condition as storage proposal. It need at least one charge & discharge cycle every six months

3. Electrical Characteristics & Test Condition

3.1 Standard Test Conditions

3.1.1 Unless otherwise specified, all performance tests is required conducted at temperature 25℃±2℃, Humidity less than 45%~75%RH.

3.1.2 Unless otherwise specified, the tested product is required unused within two month after outgoing.

3.2 Standard Charge Mode

"Standard Charge" means at 25±2℃ charge to limit voltage with 0.33C constant current, then charge with constant voltage until current less than 0.02ItA.

3.3 Quick Charge Mode

" Quick Charge" means at 25±2℃ charge to limit voltage with 0.5 C constant current, then charge with constant voltage until current less than 0.02ItA.

3.4 Standard Discharge Mode

"Standard Discharge" means at 25±2℃ discharge to the cut-off voltage with 0.33C current.

3.5 Quick Discharge Mode

"Quick Discharge" means discharge to the cut-off voltage with 0.5C current.

4. Dimensional Drawing

48V 200Ah Hybrid Residential Battery Backup System High Efficiency

5. Storage & Transportation

* Based on the character of cell, proper environment for transportation of LiFePO4 battery pack need to be created to protect the battery.

* Battery should be stayed in the ware house -20℃～35℃ where it’s dry, clean, shade, and well-ventilated.

* The battery should be stored in 50% SOC during transportation.

* The battery need to be charged every 6 months if out of use

* Keep the battery against dropping, turning over and serious stacking during loading.

6. Warning & Tips

Please read and follow the specification and caution remarks on battery surface before use the battery. Improper use may cause heat, fire, rupture, damage or capacity deterioration of the battery. Shenzhen Topband Battery Co., Ltd. Describes is not responsible for any accidents caused by the usage without following our specification.
