Durable Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty
Durable Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty
Durable Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty
Durable Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty
Durable Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty
Durable Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty
Specifications
Brand Name :
Topband
Model Number :
TB-BL12200F-S105A
Certification :
ISO9001, ISO14001
Place of Origin :
China
MOQ :
10
Payment Terms :
L/C, T/T
Supply Ability :
450Mwh/year
Delivery Time :
2~4weeks for samples; 4~6weeks for mass production
Packaging Details :
standard export carton
Price :
Negotiable
Material :
Lifepo4
Nominal Voltage :
12.8V
Normal Capacity :
200Ah
Communication function :
Bluetooth
Dimension :
485x170x245mm
Warranty :
2 years
Life time :
more than 2000 times (100% DOD)
Weight :
19.8Kg
Description

19.8Kg Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty

1. Smart Lithium battery 12V 200Ah Specification

NO. Items Criteria
1.1 Rated Capacity 200Ah
Minimum Capacity 195.0Ah
1.2 Energy 2.56KWh
1.3 Nominal Voltage 12.8V
1.4 Outgoing Voltage ≥12.8V
1.5 Internal resistance ≤20mΩ
1.6 Limited charge voltage 14.6±0.2V
1.7 Floating charge voltage 13.8±0.2V
1.8 Standard charge current 60A
1.9 Maximum charge current 80A
1.10 Standard discharge current 60A
1.11 Maximum discharge current 100A/ Continuous for 30min
1.12 Pulse discharge current 350A/Continuous for 3 s
1.13 Discharge cut-off voltage 8.0V

1.14

 Dimension Length: 485±3mm
Width: 170±3mm
Height: 245±3mm
1.15 Weight Approx: 19.8±0.5Kg

1.16

 Operating Temperature Charging:0～45℃
Discharging:-20～60℃
Recommended operating temperature:15℃～35℃
1.17 Self-discharge rate Residual capacity:≤3%/month;≤15%/years
Reversible capacity:≤1.5%/month;≤8%/years
1.18 Storage Temperature & Humidity Range Less than 1 month:-20℃～35℃,45%RH～75％RH
Less than 3 months:-10℃～35℃,45%RH～75％RH

Recommended storage environment:

15℃～35℃,45%RH～75％RH

Long time storage:

If the battery need be stored for a long time, the voltage should be 13.2V(50%SOC), and stored in the condition as storage proposal. It need at least one charge & discharge cycle every six months

2. Smart Lithium battery 12V 200Ah protection circuit specification

NO. Items Content Specification
2.1 Over charge Over-charge protection for each cell 3.80±0.03V
Over-charge release for each cell 3.60±0.05V
Over-charge release method Under the release voltage
2.2 Over discharge Over-discharge protection for each cell 2.00±0.05V
Over-discharge release for each cell 2.30±0.05V
Over-discharge release method Charging recovery
2.3 Over current Discharge over current protection 350~550A
Protection delay time 0.5~1.5s
Over current release method Release after cutoff the load.
2.4 Short NO. Ban electrode short circuit
2.5 Battery temperature Charge over temperature protection Protection @65±5℃
Release @50±10℃
Discharge over temperature protection Protection @65±5℃
Release @50±10℃
MOSFET over temperature protection Protection @100±5℃
Release @70±15℃

3. Smart Lithium battery 12V 200Ah feature

  1. High energy density
  2. High working voltage for single battery cells
  3. Pollution-free
  4. Long cycle life
  5. No memory effect
  6. Capacity, resistance, Voltage, platform time consistency is good
  7. With short-circuit production function, safe and reliable
  8. Factory price & High quality
  9. Good consistency, low self discharge
  10. Light weight, small size
  11. High discharge rate
  12. Quality and security guaranted,with CE,ROHS approval.
  13. The lifepo4 battery pack is widely used for electric bicycle,golf car,electric bike,electric wheelchair,power tools,electric scooter,emergency light,etc

4.​ Warranty:

  • The products will be checked everything is fine before ship out;
  • 2 year warranty. (The products could be Exchanged or Refunded if it defected in 2 year, in the case of correct operation according to the technical specification.)
  • Our products have received high reputation. and we own the best after-sale service. If any problems happen, our team will do our best to solve for customers.

5. Dimension

Durable Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty

6. Bluetooth Function

Bluetooth function for battery pack, it can monitor the following features from smart phones:

  • Battery pack voltage
  • Battery current draw
  • Battery state of charge
  • Battery state of discharge
  • Battery cycles
  • Battery temperature
  • Remaining capacity
  • Designed capacity
  • Full capacity
  • AverageTime to Empty
  • AverageTime to Full
  • Series Number
  • Manufacturer name

Durable Lithium Smart 12V 200Ah , Rechargeable Lifepo4 Battery 2 Years Warranty
