Agricultural Film Washing Line Plastic Recycling Machine with crushing drying
The agricultural film washing line is widely used for washing and recycling the used or waste PP/PE plastic soft plastic. Such as shopping bags, packing films, garbage bags, woven bags, non-woven bags and films. This recycling machine can be crushing washing and drying the dirty soft plastic into clean film flakes.
After plastic film/bag flakes are cleaned, you can make them into pellets/granules with the next process, which is called the plastic pelletizing machine.
This agricultural film washing line is high automatic operating and low consumption, can save labor, save power and save water, easy to maintain.
With advanced design, concepts and technologies to suit different statuses of waste plastic bags/films.
Agricultural Film Washing Line Plastic Recycling Machine Process Flow:
NO | Process | Machine | Description |
1 | Send the film and bags to the wet crusher machine | Conveyor with Metal Detector(Optional) | It separates impurities such as metals in the films and bags, Send the materials to the wet crusher machine |
2 | Cuts the films and bags into small pieces size | Wet Crusher Machine | A wet crusher cuts the PP / PE film into small pieces approximately 10-20mm in size and moves on to the next piece of equipment. |
3 | Send the films and bags to the Floating Washing machine | Screw Feeder | Put the films and bags into the friction washer to clean |
4 | The first time Floating wash the bags and films | Floating Washing Tank | As the PP / PE films enter the friction washer, the plastic film rubs against each other at high speeds getting rid of hard-to-remove contamination. |
5 | Feeding bags and film scraps to friction washer | Screw Feeder | Put the films and bags into the High-speed Friction Washer to clean |
6 | Separate the contamination from film and bags | High-Speed Friction Washing Machine | After crushing material from enters the mouth, through the high speed on the axis of the blade flap and spray water to the common function of good cleaning effect. |
7 | The second time Floating wash the bags and films | Floating Washing Tank | It is used in cleaning film and bags, making the film cleaner. |
8 | Dry the film and bags | Horizontal Dewatering Machine | The dewatering machine uses centrifugal force to spin water moisture off the films and bags. |
9 | squeezer to dry the films and bags | squeezer machine | Using the film squeezer machine to take the humidity away from the clean material and the final film product is pop corn. |
10 | Storage dry pieces of films and bags | Storage silo | A storage tank for the clean, dry pieces of PP PE films and bags. |
11 | make film and bags into granules(Optional) | Pelletizer / Extruder | We also make and design both single-screw extruders and twin-screw extruders. Based on your requirements, we offer both one-stage and double-stage pelletizing setups where granules can be formed using a granulator or water-ring cutting. |
Agricultural Film Washing Line Plastic Recycling Machine Features :
To crushing washing recycling the used, dirty waste PP PE films/bags, protect the environment, and avoid white pollution.
This recycling line is composed of crusher, cold & hot washing system, dewatering, drying, packing system, etc.
This PP PE waste plastic crushing, recycling and washing recycling machine line can easily wash and recycle waste PP PE films/bags. Waste and dirty PP PE films/bags can be processed step by step, by this recycling machine. It is special for washing PP PE films/bags. We can help to attach equipment at the end of the washing recycling line so that the completely dry flakes can be collected and packed directly after being washed.
The whole production line can design based on how dirty the PP PE films/bags are, and make sure of the quality of the final products.
Coordinating the production line with follow programmed work (granulating system), and will make waste and dirty PP PE films/bags to be the PP PE granules material and in order to produce new PP PE products.
