Specifications
Brand Name :
BEAKELAND
Model Number :
ML100
Certification :
CE
Place of Origin :
JIANGSU,CHINA
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
15 sets per year
Delivery Time :
65 working days
Packaging Details :
Wooden case packing for LCL shipment, Film wrap packing for FCL shipment.
Machine Name :
Film Recycling Granulating Machine Line
Screw diameter :
100
L / D :
33
Screw Design :
Single screw extruder
Plastic processed :
PE,PP,HDPE,LDPE film
Capcacity :
250 - 350 kg / h
Agglomerator motor :
55KW
Extruder motor :
90KW
Description

Film Recycling Granulating Line

Description:

Film Recycling Granulating Machine Line with international advanced recycling technology and combined with the actual application condition. This plastic pelletizing recycling machine is design specializes for recycling the washed plastic PE film, such as PE plastic bags, plastic packing films, plastic shopping bags, plastic handbag etc.

After processing techniques such as compression, heating, melt, pelletizing, cooling, drying etc., the final products are plastic pellets, granules, which can be to produce garbage bags, drainage pipes, plastic board etc.

Single stage extruder is normally designed for good cleanliness and low moisture material,such as leftover material from the film/bag production line, printed films ect.

Components:

Film Recycling Granulating Machine Line mainly consists of Belt conveyor, Cutter Compactor, Single Screw Extruder, Degassing, Hydraulic Screen Changer, Die Mould, Water ring Pelletizing or Spaghetti Pelletizing, Centrifugal Dewatering or Cooling Water Tank,Vibration machine,Air blowing and Silo, Electric Control Panel.

Optional devices:

Metal detector

Roll hualing off deice

Masterbatch / Additives feeder

Technical parameters for LDPE LLDPE HDPE Film Granulating Machine Line:

Series Model Screw Diameter(mm) L/D Capacity (kg/h)
ML SJ65 65 33:1 60-100
SJ85 85 33~36:1 100~250
SJ100 100 33~36:1 200-350
SJ130 130 33~36:1 400-600
SJ160 160 33~36:1 650-800
SJ180 180 33~36:1 700-1000

Advantages:

  • High output and low energy consumption.
  • Very low labor request.
  • Stable running.
  • Automatic constant temperature control.
  • CE certification, ISO9001 certification, SGS certification
  • Configuration based on client requirement and material, and give reasonable suggest.

More Photos for Film Recycling Granulating Machine Line :

LLDPE Single Screw Extruder Machine 350Kg H Plastic Film Washing Line

LLDPE Single Screw Extruder Machine 350Kg H Plastic Film Washing Line

LLDPE Single Screw Extruder Machine 350Kg H Plastic Film Washing Line
