OTS650 Surveying Instrument 1000m Reflectorless Total Station
OTS650 Surveying Instrument 1000m Reflectorless Total Station
OTS650 Surveying Instrument 1000m Reflectorless Total Station
OTS650 Surveying Instrument 1000m Reflectorless Total Station
Specifications
Brand Name :
FOIF
Model Number :
OTS650
Certification :
ISO
Place of Origin :
China
MOQ :
1 Piece
Payment Terms :
T/T
Supply Ability :
100 pieces per month
Delivery Time :
10~20 Work Day
Packaging Details :
Carton
Model :
OTS650
Image :
Erect
Magnification :
30X
Single Prism :
6000m
Reflectorless :
1000m
Accuracy :
2''
Measuring Range :
2.0 to 600m (800m optional)
Prism Accuracy :
1.5mm+2ppm
Measuring Time :
Initial: 2.5sec
Compensator :
Dual-axis
Setting Accuracy :
1''
Plate Level Vial :
30''/2mm
Circular Level Vial :
8'/2mm
Battery :
3400mAh Li-ion Rechargeable
Output Voltage :
7.4V DC
Operation Time :
12 Hours
Display :
Large LCD (240*128 dots)
CPU :
32Bit
Description

OTS650 Surveying Instrument 1000m Reflectorless Total Station Single Prism 6000m

Model: OTS650

Specification:

Model OTS650
Image Erect
Magnification 30X
Shortest Focus Distance 1.0m
Reading System Absolute encoder
Accuracy of RTS680 2’’
Prism 1.0-1.5s
Measuring Range 2.0 to 600m (800m optional)
Prism Accuracy 1.5mm+2ppm
Measuring Time Initial: 2.5sec
Compensator Dual-axis
Setting Accuracy 1’’
Plate Level Vial 30’’/2mm
Circular Level Vial 8’/2mm
Laser Plummet Accuracy 1mm/1.5m
Optical Plummet Accuracy 0.8mm/1.5m
Battery 3400mAh Li-ion Rechargeable
Output Voltage 7.4V DC
Operation Time 12 Hours
Charger FDJ6-LI(11v/24v)
Charging Time 4 Hours
Display Large LCD (240*128 dots)
CPU 32Bit
Memory 128M internal memory, support SD card
Keyboard Alphanumerical, both sides
Weight 15Kg
Dimension 185*220*360mm
Data Transfer Software FOIF Geomatics Office
Water and dust Protection IP55

Introduction:

EDM technology is improved, its powerful long reflectorless measuring distance can reach 600m/1000m

Power long reflectorless measuring distance 300m (R300)/ 500 (R500)

Bluetooth cable-free connection

128Mb internal memory, 120000 points and 40 jobs can be saved

Can be operated with a data collector, FOIF FieldGenius or Carlson SurvCE

IP66 environmental protection

Alphanumeric keyboard

Features:

A. Dual Screen

B. SD card, Bluetooth

C. USB, RS232

D. Two Batteries with over 26 hours of working time

FOIF Total Station

FOIF provides total station solutions to meet all your surveying needs. Measurements have never been so easy to perform as with the FOIF Total Station, which allows beginners and professionals to do the job quickly and efficiently.

Overview of RTS100 Series Total Station

1. Alphanumeric Keyboard

2. Reflectorless measuring distance: 600m(R600)

3. Bluetooth cable-free connection (Factory Optional)

4. 120000 points and 40 jobs can be saved.

5. Can be operated with a data collector, FOIF FieldGenius, or other third party software is available.

Package: Hard Carrying Case

OTS650 Surveying Instrument 1000m Reflectorless Total Station

Detailed Pictures

OTS650 Surveying Instrument 1000m Reflectorless Total Station

OTS650 Surveying Instrument 1000m Reflectorless Total Station

OTS650 Surveying Instrument 1000m Reflectorless Total Station
