High Strength 99% Aluminum Oxide Ceramic Thread Guides With High Polishing
High Strength 99% Aluminum Oxide Ceramic Thread Guides With High Polishing
Specifications
Brand Name :
KAMTAI
Model Number :
KTJC18
Certification :
ISO 9001
Place of Origin :
CHINA
MOQ :
2000PCS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram,PAYPAL
Supply Ability :
10000PCS/ MONTH
Delivery Time :
25 DAYS AFTER PAYMENT
Packaging Details :
CARTON BOX AND PLYWOOD PALLET
Young's Modulus :
＞280GPA
Vickers Hardness :
＞12GPA
Product Name :
Various popular design of 99% Alumina Ceramic Ceramic Thread Guides with high polishing
Application :
Textile machine
Features :
High strength and High temperature resistance
Using life :
Long
Description

Various popular design of 99% Alumina Ceramic Ceramic Thread Guides with high polishing

Applications and Features:

1. Ceramic eyelet guides (Ceramic ring ) and zirconia ceramic eyelet are applied to the coiling machine and spinning and weaving machinery, it is in common use fault silk another piece.

2. Silk thread slides when the job, in China eye outside, for reducing friction, must raise material hardness, smoothness and form.

3. Our company selects and uses 99%'s Al2O3, hardness greater than HRa88, density 3.85, surpasses essence throwing Ra0.2.

4. The alumia ceramic (Textile ceramic eyelet) Zirconia ceramic eyelet is used to set less (friction is also less) location of pressure right.

5. For cost reduction, according to using a request, smoothness polishing handicraft is allotted being (0.8 throw Ra) roughly, is throw (Ra accurate 0.4), surpasses essence throwing (Ra0.2).

Advantages:

1) Wear resistant


2) Corrosion resistant


3) Heat resistant


4) Stable dimensions


5) Long performance life, low friction

Structures:

1. The inside surface Polish degree: Ra0.2~0.8.


2. The material: 99% AI2O3 with density of 3.85.


3. The hardness: HRa88.


MATERIAL PROPERTIES

Unit 95% Al2O3 99% Al2O3 ZrO2
Color - white ivory white
Density g/cm³ 3.65 3.88 5.95
Water Absorption % 0 0 0
Young's Modulus Gpa 280 350 205
Vickers Hardness Gpa 14 20 12
Flexural Strength ( at R.T. ) Mpa 280 300 900
Compressive Strength ( at R.T. ) Mpa 2000 2500 2200
Thermal Conductivity ( at R.T. ) W/(m.K) 18-25 30 2.2
Thermal Shock Resistance ΔT(°C) 220 180-200 280-350
Max. Working Temperature ( at R.T. ) °C 1500 1700 850
Volume Resistivity ( at R.T. ) Ω.cm >10^15 >10^14 >10^12
Dielectric Constant (1 MHz at R.T. ) - 9.50 9.80 26
Dielectric Strength kV/mm 16 22 -
