Lightweight Long Performance Life 95-99 Alumina Ceramic Eyelet For Textile Machine
Lightweight Long Performance Life 95-99 Alumina Ceramic Eyelet For Textile Machine
Specifications
Brand Name :
KAMTAI
Model Number :
KTJC15
Certification :
ISO 9001
Place of Origin :
CHINA
MOQ :
1000PCS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram,PAYPAL
Supply Ability :
10000PCS/ MONTH
Delivery Time :
25 DAYS AFTER PAYMENT
Packaging Details :
CARTON BOX AND PLYWOOD PALLET
Name :
Lightweight And Long Performance Life 95-99 Alumina Ceramic Eyelet
Material :
95 & 99 Alumina ceramic
Shape :
Eye
Application :
Textile machine
Features :
High strength and High temperature resistance
Using life :
Long
Description

Textile ceramic eyelet apply to the coiling machine and spinning and weaving machinery, is in common use fault silk another piece, is used to demand no high fault silk occasion. Silk thread slides when the job, in China eye outside, for reducing friction, must raise material hardness, smoothness and form. Our company selects and uses 99%'s Al2O3, hardness greater than HRa88, density 3.85, surpasses essence throwing Ra0.2.

The textile cramic eyelets is used to set less (friction is also less) location of pressure right. For cost reduction, according to using a request, smoothness polishing handicraft is allotted being (0.8 throw Ra) roughly, is throw (Ra accurate 0.4), surpasses essence throwing (Ra0.2).

Ceramic eyelets Be that single face is super-accurate at the same time mark throw and two-sided super-accurate throw. Specification of China eye many, select and use specification listing in common use in sopport a customer the day afer tomorrow now, also may demand making to order according to the customer.

Other information:

Feature Application Main usage
1.Great mechanical strength

Electric appliance industry

Automotive industry

1.Heat treatment furnace

and toughened furnace
2.High softening temperature
3.Good resistance to thermal impact
4.Small thermal expansion coefficient

Mechanical industry

Engineer industry

2.Inner liner tube and heating

tube in electric furnace
5.Good chill and abrupt heat properties
6. Resistance to acid and alkali corrosion

Alumina Ceramic Eyelet Properties:
Properties Units Alumina(Al2O3)
Porous Mullite Al2O3 92%

Al2O3

96%

 Al2O3 99% Al2O3 99.5%
Al2O3
Mechanical Density g/cm3 2.8 3.6 3.7 3.9 3.9
Color —— —— Tan White White Ivory Ivory
Water Absorption % 0 0 0 0 0
Vickers Hardness Gpa —— 7.4 11 11.5 13 14
Flexural Strength (20°C) Mpa 50~100 170 345 358 380 380
Compressive Strength (20°C) Mpa 20~100 550 2200 2300 3000 3000
Thermal Thermal Conductivity (20°C) W/m.K 3.1 3.5 16.7 24.8 25~35 25~35
Thermal Shock Resistance (20°C) ΔT(C) —— 300 250 250 200 200
Maximum Use Temperature °C 1900 1700 1500 1600 1700 1700
Electrical Volume Resistivity (25°C) Ω.cm —— >1014 >1014 >1014 >1014 >1014
