High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
Specifications
Brand Name :
KAMTAI
Model Number :
KTALP-1-R9
Certification :
SGS
Place of Origin :
CHINA
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram,PAYPAL
Supply Ability :
15000PCS/ MONTH
Delivery Time :
25 DAYS AFTER PAYMENT
Packaging Details :
CARTON BOX AND PLYWOOD PALLET
Highest application temperature :
1500 ℃
Bending strength :
300Mpa
Insulation breakdown strength :
15-18
Hardness :
1800 HV 0.5
Alumina Content :
>95%
Description

High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance

1.Description

Alumina ceramic is kind of structural ceramics, with insulation resistance, voltage resistance, high strength, good thermal conductivity, dielectric loss, stable electrical performance characteristics. Used in electronic ceramic substrates, ceramic electrical insulation, vacuum devices, devices porcelain, spark plugs and other products. We can make the part by hot injection pressing, dry pressing, isostatic pressing and extrusion productive technology etc.

2.Advantages:
1). Excellent insulation, security, long working life.2). High temperature resistance3). Resistance to electric breakdown4). Stand wear and tear5). High strength6). Corrosion resistance7). Good compactness8). HIgh hardness

3.Data Sheet

Material Unit Steatite 95% Alumina 99.5% Alumina
Density G/cm3 2.7 3.65 3.85
Highest application temperature °C 1100 1500 1800
Bending strength Mpa 150 300 340
Compressive strength Mpa 900 3400 3600
Hardness HV0.5 800 1800 2000
Insulation breakdown strength KV/mm 10 15-18 18
Processing technology
Process range (mm)
Outside Diameter 1---300
Inside Diameter 0.5---300
Length 0.5---1200
Accuracy of working (mm)

4..Application

Aluminum Oxide Ceramic Sheet / Alumina Wear Ceramic Plate is widely used for serious abrasive environments, such as chute liners, cyclone liners, conveyor skirt liners, processing piping liners, hopper or silo liners, screen equipment liners in the industries including ,but not limited to:

High Performance Aluminum Oxide Ceramic 95% Al2o3 Plate Good Heat Resistance
