SIC Silicon Carbide Ceramic Kiln Plates 280MPA Slabs For Household Porcelain Firing
SIC Silicon Carbide Ceramic Kiln Plates 280MPA Slabs For Household Porcelain Firing
SIC Silicon Carbide Ceramic Kiln Plates 280MPA Slabs For Household Porcelain Firing
SIC Silicon Carbide Ceramic Kiln Plates 280MPA Slabs For Household Porcelain Firing
Specifications
Brand Name :
KAMTAI
Model Number :
KTRKF10000
Certification :
ISO
Place of Origin :
CHINA
MOQ :
200 PCS
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram,Paypal
Supply Ability :
5000PCS/MONTH
Delivery Time :
25 DAYS AFTER PAYMENT
Packaging Details :
PLYWOOD BOX AND PALLET
Al2O3 Content (%) :
1.34%
CaO Content (%): :
0.34%
working temperature: :
1400
Bending Strength 1200℃: :
280MPA
Size :
Customize
Shape :
Plate
Bulk Density :
2.75g/cm3
Description

silicon carbide kiln plate

1.Chemical and Physical index of silicon carbide plate:

Main Performance Index of Silicon Carbide(SiC)
Item Unit SiC
Purity % ≥90
Density g/cm3 2.75
Shore Hardness HS 110-125
Elastic Modulus Mpa 4.12x105
Poisson Ratio 0.15
Tensile Strength Mpa 2.75 x102
Bending Strength Mpa 4.41 x102
Compression Strength Mpa 2.94 x103
Thermal Conductivity W/m.k 141 (W/m.k)
Coefficient ofThermal Expansion l/ºC 4.3x10-6
Heat Resistance 1600C
Thermal Impact Coefficient cal/cm.sec 46.5
Acid Resistance 5 times higher than the usual TC

2. Description

Taking silicon carbide as the main material and adding expansion agent and anti oxidant, SIC silicon carbide ceramic kiln plates or slabs for household porcelain firing have very high load softening temperature and excellent anti oxidative effect through vibration supported uniaxial press compaction and high temperature firing. It was originally used as an alternative to conventional bonded SiC materials, but it shows the long term stability comparable to RSiC and NSiC with lower cost.

3.Property:

Good thermal shock resistance

Good resistance against corrosion and oxdiation

Good mechanical strength at high temperature

Excellent thermal and electric conductivity

Long service life and energy saving

Environmental friendly

Other recommendations

Reaction Bonded SiC (SiSiC)

Recrystallizde SiC (RSiC)

Nitride Bonded SiC (NSiC)

Shapes of SIC silicon carbide ceramic kiln plates or slabs for household porcelain firing

Batts, setter plate, pusher plate, setter slab, sagger,muffle board,support shelves and other special shaped products

Remark: sizes and shape are available upon requests.
