Customized Air Cooled Condensing Units R404a For Vegetable Chiller
Customized Air Cooled Condensing Units R404a For Vegetable Chiller
Customized Air Cooled Condensing Units R404a For Vegetable Chiller
Customized Air Cooled Condensing Units R404a For Vegetable Chiller
Customized Air Cooled Condensing Units R404a For Vegetable Chiller
Customized Air Cooled Condensing Units R404a For Vegetable Chiller
Specifications
Brand Name :
Gaoxiang
Model Number :
GXN6CBFZD
Certification :
CE , ISO
Place of Origin :
China
MOQ :
1Pc
Price :
Negotiation
Payment Terms :
L/C , T/T
Supply Ability :
100Pcs / Month
Delivery Time :
20 ~ 25 Days
Packaging Details :
Standard Export Packing
Type :
Refrigeration Machine
Refrigerant :
R404a
Power Supply :
220 - 380 - 440 - 460 V / 3ph - 60Hz
Usage :
Vegetable Chiller
Expansion Valve :
Danfoss
Condenser :
Air Cooling Condenser
Description

Customized Air Cooled Condensing Unit For Vegetable Chiller

Product Description :

1 . With ECOLINE series semi - hermetic compressor .
2 . With copper tube - Alu . Fin air cooled condenser or high efficient shell - tube water cooled condenser
3 . Air cooled condensing units with low noise and high efficient external rotor fan motor .
4 . With high quality China made or imported components .
5 . System with water - proof cable connection box for easy connection .
6 . A complete product range with wide temp . Range available , can be used for keeping fresh , cold storage , ice making and cold water etc . " .

Product Assembly unit

Pressure controller
Liquid accumulator
Crankcase heater
Solenoid valve
Condenser
Semi-hermetic screw compressor
High / low pressure gauge
Junction box Filter

Air - Cooled Refrigeration Unit Technical parameters :

1 . Condenser Details :

Qty Of Fan ( piece ) Air Volume ( m3 / h ) Power of Fan ( W )
2 2 * 3200 2 * 60

2 . Refrigerant Capacity Of Compressor :

a. Evaporating Temperature - 5 ℃

Cooling Capacity 10100 W
Power 5920 W

b . Evaporating Temperature - 12 ℃

Cooling Capacity 8060 W
Power 5570 W

3 . Coupling

Tube Coupling 1 / 2 〞
Suction Coupling 3 / 4 〞

4 . Overall Dimensions :

Length ( L ) 980mm
Width ( B ) 410mm
Height ( H ) 1330mm

5 . Mounting Dimensions :

Length ( D ) 625mm
Width ( E ) 380mm
