Specifications
Brand Name :
THERMO KING
Model Number :
RV580
Place of Origin :
China
MOQ :
2
Price :
USD
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 Unit
Delivery Time :
20-35 work day
Packaging Details :
standard parking
Brand Name: :
THERMO KING
Refrigerant: :
R404a
Compressor: :
Oil-free
Color: :
White
Structure: :
Truck Body, Front Mounted Installation
Installation Kits:: :
Rubber Hoses, Drain Water Hoses, Wiring Harness Etc
Condition: :
New
Box Dimensions ( Lx W x H) (mm): :
x W x H) (mm): 3m-7m
Description
RV series RV-200/300/380/580 thermo king 12v/24v cooling system refrigeration units for truck

product Introduction:

RV-Series:

RV, as the acronym of Rapid cooling/Reliable/Revolution Vehicle-powered, is specially designed for transport refrigeration in the range of light

and medium distribution vehicles.
This all new RV platform is equipped with an optimized refrigeration system, robust TK compressor, and other proven components, which ensures
high cooling capacity, quick pull down, precise temperature control, high reliability, easy use and low maintenance cost
Model RV-200 RV-300 RV-380 RV-580
Temp. Range -25℃~+30℃
Refrigerant R-404A
Charge (kg)

1.10

(TK08 compressor)

1.15

(TK15 compressor)

 1.2 1.8 2.5
Compressor
Model TK08 TK15 TK15 TK16 TK16
Number of Cylinder 6 6 6 6 6
Displacement (cm3) 82 146 146 163 163
Cooling Capacity (W) A.T.P. U.N. Standard @30℃ (Ambient)

Cooling Capacity (W) A.R.I. U.S. Standard @38℃ (Ambient)

Engine Power

 2℃ 2,000 2,200 3,300 3,800 4,900
-18℃ 800 1,150 1,740 2,200 2,520
Evaporator blower performance
Flow rate (@ 0 static pressure, m3/h) 700 1,500 1,500 2,500
Velocity (m/s) 3.0 3.3 3.3 3.0
Total current consumption on the road (A)
12 VDC 30 36 36 44
24 VDC 15 18 18 22
Weight (kg, approximate)
Condenser

24 (roof-mounted),

23 (nose-mounted)

24 (roof-mounted),

23 (nose-mounted)

30

35
Evaporator 9 15 18 30
Compressor 4.1 (TK08), 4.3 (TK15) 4.3 4.7 4.7
.

RV-Series Dimension(mm):
RV-Series Key Features:
Greater Capacity and Higher Efficiency
Larger condenser/evaporator coil for quicker heat exchange Fast pre-cooling for higher efficiency
Greater cooling capacity for better load protection
Compact Design and Flexible Installation Patent design (RV-380 patent no. ZL201530106353.5) Light and compact for easy installation, esp. for light and mini vehicle
Roof-mounted & nose-mounted for option (RV-200/RV-300)
RV Sriese 24V 22A Thermo King Container Refrigeration
Application scenario
