Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)
Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)
Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)
Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)
Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)
Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)
Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)
Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)
Specifications
Model Number :
CSW7583-80(Y)
Certification :
CE, CSA, GS, ROHS, UL
Place of Origin :
Germany
MOQ :
1
Price :
discussed
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
15 pcs
Delivery Time :
20-25DAYS
Packaging Details :
wood packaging
Horse power :
Germany
Power supply :
400-460/3/60Hz,400-460/3/50Hz
Refrigerant :
R-22,R407C
power source :
ac power
After-sales Ser :
Engineers available to service
Description

screw compressor service manual, compressor catalogue CSW7583-100(Y)

1,CSH Series with R-22,R-134a,R407C
2,CSW Series with R-22,R-134a,R407C

Semi-hermetic Screw compressor

Description:

1. Semi-hermetic screw compressor, specially used for low temperature application and big capacity demand.

2.With development of refrigeration market, more and more big freeze room are required, screw compressor rack is perfectly applicable for it.

3.The professional design is made to protect inversion, overheat, overload, exhaust temperature, low oil level, oil flow.

4.It is widely used in different field, like supermarket, food industry, chemical industry, hotel, restaurant, and even medical service, etc

Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)

Green And Big Screw Compressor With R-22 R-134a R407C , CSW7583-100(Y)

Technical data and Performance data
compressor
type		 Motor version DispIace-ment
50/60Hz		 Refrigerating capacity Qo Oil Charge Motor connection Max.
operating
current		 Max.
power
consum
to/tc
5℃/50℃		 to/tc
-10℃/45℃
① ② m3/h③ W W dm3 A④ KW④
CSHP6553-50P 1 137/165 97630 61610 9,5 400V(±10%)∆/∆∆-3-50Hz
460V(±10%)∆/∆∆-3-60Hz
Part Winding
---
400V(±10%)∆-3-50Hz
460V(±10%)∆-3-60Hz
Y/∆⑤		 86 52
CSHP6563-60P 1 170/205 122500 77360 9,5 108 65
CSHP7553-70P 1 197/238 140900 86770 15 128 78
CSHP7563-80P 1 227/274 162500 100800 15 144 88
CSHP7573-90P 1 258/311 188500 117900 15 162 96
CSHP7583-100P 1 295/356 219800 139400 15 170 101
CSHP7593-110P 1 336/406 250200 158400 15 180 112
CSHP8553-110P 1 315/380 236200 151900 22 185 112
CSHP8563-125P 1 535/646 269200 173100 22 216 132
CSHP8573-140P 1 535/646 310700 199900 22 246 150
CSHP8583-160P 1 535/646 337300 212800 19 260 160
CSHP8593-180P 1 615/742 393100 247900 19 310 186
CSHP9553-180P 1 700/845 395000 248400 30 400V(±10%)∆-3-50Hz
460V(±10%)∆-3-60Hz
Y/∆⑤		 330 205
CSHP9563-210P 1 805/972 460600 291900 30 370 246
CSHP9573-240P 1 910/1098 532300 339900 30 420 255
CSHP9583-280P 1 1015/1225 613500 392600 30 450 280
CSHP9593-300P 1 910/1098 709800 454600 30 450 280
CSHP95103-320P 1 1015/1225 764700 485800 32 566 350
