DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
Specifications
Brand Name :
DAIKIN
Model Number :
JT1G-VDK1YR
Certification :
CE, ROHS
Place of Origin :
Japan
MOQ :
1pcs
Price :
discussed
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5,000pcs per month
Delivery Time :
7-10 working days after receiving payment
Packaging Details :
Wooden case
Piston Type :
Rotary
Configuration :
Stationary
Power Source :
AC Power
Lubrication Style :
Lubricated
Drive Mode :
Electric
Type :
Refrigeration Piston Compressor
Temperature :
Middle/High
Horse Power :
5HP
Voltage :
380-440V/50Hz
Refrigerant :
R410A
Size :
450*1500*1500mm
Colour :
black
Weight :
60kg
Description

DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR

JT1G-VDL daikin scroll air compressor

power source: 380-415v,50Hz 400-440v,60Hz

current:8.9A

cop: 4.2W/W

displacement:56cm3/r

output:5 Hp

Daikin compressor Product Description

Performance Features

1) High Efficiency

We provide high efficiency compressors by greater accurate maching, particular assembling and oil seal technology

2) Low Sound Levels

Using un-contact scroll, we have accomplished low sound power levels and low vibration

3) High Reliability, long operating life

DAIKIN compressor have fewer moving parts than others, low reiteration impulsion and low sliding velocity

4) Wide operating voltage range

DAIKIN compressor guaranteed within voltage range 10%

5) Special value

Due to simplifying system design and saving cost, it would enhance your product competitive in the market to us DAIKIN compressor

6) Cooling capacity: 3hp, 3.5hp, 4hp, 4.5hp, 5hp, 6hp

7) Refrigerant: R22. R407c. R410a

8) Power: 220v-240v / 50hz, 380v-420v / 50hz, 380v-420v / 60hz

9) High ambient: 65 degree

10) Packing: 24pc / pallet

We can supply more compressor models as below:

MODEL

OUTPUT

(HP)

POWER

SOURCE

(V/Hz)


PERFORMANCE

TUBE CONNECTIONS

NETWEIGHT
INCLUDING 0IL
(Kg)

NOMINAL

CAPACITY

(W)

INPUT

(kW)

(W/W)

dB(A)

SUCTION TUBE
mm

DISCHARGE TUBE

mm

JT90GABY1L

3

380/50

8410

2.47

3.4

61

φ 22.1

φ 16

29.0

JT95GABY1L

3

380/50

9070

2.67

3.4

61

φ 22.1

φ 16

29.0

JT125GABY1L

4

380/50

11700

3.44

3.4

63

φ 22.1

φ 16

31.6

JT160GABY1L

5

380/50

14600

4.30

3.4

63

φ 22.1

φ 16

32.2

JT170GABY1L

5

380/50

15600

4.59

3.4

63

φ 22.1

φ 16

33.1

daikin compressor
Model Output (HP) Power Source (V/Hz) Performance

Nominal

Capacity (W)

 Input Power (Kw) COP (W/W) Noise (dB)
JT90BCB-V1L 3 220/50 8540 2.89 2.96 58
JT90BC-Y1L 3 380/50 8540 2.75 3.11 58
JT95BCB-Y1L 3 380/50 8540 2.75 3.11 58
JT95BC-Y1L 3 380/50 9030 2.89 3.12 58
JT125BC-Y1L 4 380/50 11900 3.8 3.13 60
380/60 14200 4.53 3.13 63
JT125BCB-Y1L 4 380/50 11900 3.8 3.13 60
380/60 14200 4.53 3.13 63
JT160BC-Y1L 5 380/50 15000 4.66 3.22 60
380/60 17900 5.53 3.23 63
JT160BCB-Y1L 5 380/50 15000 4.66 3.22 60
380/60 17900 5.53 3.23 63
JT212D-Y1L 7.5 380/50 21500 6.49 3.31 72
JT212D-YE 400/60 25100 7.66 3.28 75
JT236D-Y1L 7.5 380/50 24000 7.2 3.33 72
JT236D-YE 400/60 28300 8.53 3.32 75
JT265D-Y1L 8 380/50 26700 7.95 3.36 72
JT265D-YE 400/60 31800 9.45 3.37 75
JT300D-Y1L 10 380/50 29900 8.85 3.38 72
JT300D-YE 400/60 35200 10.4 3.38 75
JT315D-Y1L 11 380/50 31100 9.15 3.4 72
JT335D-Y1L 12 380/50 34000 9.98 3.41 72
JT335D-YE

400/60

 40100 11.8 3.4 75

DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
