Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
Specifications
Brand Name :
HengXiang
Model Number :
ST004 3036B
Certification :
CE
Place of Origin :
China
MOQ :
300 PCS
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
50000PCS Per Week
Delivery Time :
30 Working days
Packaging Details :
Cartons
Material :
Welding Vinyl Tube Sealing
Type :
Refrigerator Parts
Color :
Pink, White
Power Source :
Electric
Voltage :
250 VAC
Feature :
Snap-Action Automatic
Life Cycle: :
100,000 Cycle
Operating Temperature :
Open:12℃ Close:-5℃
Warranty :
1 Year
Loading Port :
Shanghai or Ningbo
Delivery Term :
By Sea or By Air
Description

Defrost Sensor and Thermal Fridge Spare Parts Defrost Thermostat with fuse for Refrigerator

Product Description

The Series 1/2 "(12.7mm) bimetal defrosting section thermostat is used for the temperature control of refrigerators and air conditioners, as well as for the automatic temperature control of dehumidifiers and refrigerators heating and defrosting and the safe arrangement of system temperature limit. Structure features: resin seal, electrical parts completely sealed, easy installation, moisture-proof, moisture-proof, etc.


Main Technical Specification:
Action Feature: Single Cutter,, Single Throw(SPST)
Electric Rating: 250VAC SA
Insulation Resistance:≥10M2
Action Temperature Range:-30℃~90℃

Product Info

ltem NO. ST-004 3036B
Use Defrost/Temperature control/Protection
Appliance Refrigerators, Freezer
Reset type Automatic
Basic material Bakelite, Copper, Silver
Amperage 5A
Max. Operating Temperature 90°C
Differential According to the requirement
Min. Diff 8°C
Tolerance Refer to the regulation
Cold-resistant Temperature -30°C
Limit of the tolerance(OFF) ±3°C
Limit of the tolerance(ON) ±3°C
Contact material Silver
Dielectric Strength Parts between electriferous components and non-electriferous ones can bear 2000V (3750V for Reinforced insulation type) 50Hz AC
current, which is nearly sine wave, for one minute as bearing test. Resulted no breakdown, no flashover.
Insulation Resistance With a DC 500V megger, borne DC 500V, the tested value is over 10MW.
Resistance Between Terminals Below 50mW
Temperature characteristics Normal close, Normal open
Maximum Ambient Temperature 90°C
Diameter of Bimetal Disc F12.7mm(1/2″)
Tube Color Pink
Terminal type Customized (Refer to our specification)
Cover/Bracket Customized (Refer to our specification)

Variable temperature area sensor:

Temperature sensor: Use for displaying the temperature and control of the variable temperature room (the temperature in this area is generally between -7 degrees to 5 degrees)

Defrost sensor: Temperature sensor generally disconnected at normal temperature, closed below -7 °C ! The defrost heater is electrified to heat up and defrost the evaporator! (In a refrigerator, this sensor must be used with a fuse)

Ice temperature sensor: Temperature sensor apply to display the temperature of the ice temperature area Refrigeration evaporator sensor: temperature sensor, used to control the temperature of the refrigerator compartment.

Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse

Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse

Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse

Packaging & Delivery

Single package size: 20X10X5 cm

Single gross weight: 0.500 kg

Package:45*35*30CM 500PCS/CTN GW:16KGS NW:15KGS

Vinyl Defrost Refrigerator Appliance Parts Thermostat With Fuse
