High Brightness Front Service LED Display , 500x500mm LED Signs With Front Access
High Brightness Front Service LED Display , 500x500mm LED Signs With Front Access
High Brightness Front Service LED Display , 500x500mm LED Signs With Front Access
High Brightness Front Service LED Display , 500x500mm LED Signs With Front Access
High Brightness Front Service LED Display , 500x500mm LED Signs With Front Access
High Brightness Front Service LED Display , 500x500mm LED Signs With Front Access
Specifications
Brand Name :
Reiss
Model Number :
p2.976
Certification :
CE ROHS FCC EMS
Place of Origin :
Shenzhen
MOQ :
1
Supply Ability :
200000000000
Packaging Details :
wooden case
Price :
Negotiable
Usage :
Indoor,Outdoor
Display Function :
Video
Product Name :
LED Signs With Front Access
Feature :
High Brightness
Description

HD Full Color SMD LED Panel Indoor P2.976 LED Display Screen

1. High brightness which is adjustable to sufficiently meet the needs of various application environments;

2. The raw material of all of the outdoor products including LED chips, mask, glue and steel cabinets have the ability
of enduring high temperature and high humidity, and being anti-UV, waterproof, anticorrosion and antirust;
3. Every production process is well controlled and all of the electronic components are covered by 2mm Tri-Guard
Lacquer to ensure no oxidation, no rusty and no moisture. Five-Guard Lacquer will be used for special requirements;
4. All of the cabinets are tested by flush, shower and soaking, to ensure the waterproof;
5. Display even after long-term use of perfect quality reproduction and enough brightness and white balance.
Full Color P2.976 LED Display
Main
Model
CK-P2.5-32S
Module
Pixel pitch(mm)
2.976
LED Lamp Model
SMD2121
Module Size(W*H)
250*250 mm
Module Size(W*H)
Module Resolution(W*H)
64*64
Driving Mode
Constant drive
Scan Mode
1/32
Pixel configuration (R,G,B)
1R,1G,1B
Color temperature (K) :
3200-9300
Grey scale/colors
256levels of each color(RGB)/16.7M colors
Cabinet
Standard Cabinet Size(mm)
480*480*60
(W*H*T)
Cabinet Resolution(W*H)
/
Cabinet Module Number
4PCS
IP Grade
IP30
Cabinet Weigh(kg)
5.5
Cabinet Material
Die Casting Aluminum
Display
Best Viewing Distance(m)
2-50
Pixel Density (dot/m2)
112896
Brightness(cd/m2)
≥1200
Power Max Consumption (W/m2)
≤1200
Power Average Consumption (W/m2)
400
View angle
H:160; V:160
system Specification
Control host (CPU) :
Pentium4 or above
Operating system:
WIN98/2000/NT/XP
Control method
Synchronous display with control PC by DVI
Control System
Linsn, Nova-star, Colorlight or as you required
Display Content
Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
Interface definition
HUB75
Frame Frequency
≥60Hz
Refresh frequency
1920HZ/3840HZ
Transmission Distance
Multi mode fiber <500m, single mode fiber <30km,internet cable
Operation Parameter
Working Voltage
AC220±10% 50Hz/AC110±10% 60Hz
storage Temperature
35℃～+85℃
Working Temperature
-20℃～+55℃
Humidity
10%-95%
Life Span Time
≥100000 hours
MTBF
≥5,000hours
Screen Plainness
＜±1mm
Blind Spot Rate
＜0.0001
　
Certificate
CE, RoHS, FCC

High Brightness Front Service LED Display , 500x500mm LED Signs With Front AccessHigh Brightness Front Service LED Display , 500x500mm LED Signs With Front Access

High Brightness Front Service LED Display , 500x500mm LED Signs With Front AccessHigh Brightness Front Service LED Display , 500x500mm LED Signs With Front Access
