P1.875 Indoor Full Color LED Display 480*480mm High Precise Die Cast Aluminum Cabinet
P1.875 Indoor Full Color LED Display 480*480mm High Precise Die Cast Aluminum Cabinet
Specifications
Brand Name :
REISS
Certification :
ROHS CE UL FCC EMS
Place of Origin :
Shenzhen
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Delivery Time :
7-10 work days
Product name :
Small pixel pitch led display
Usage :
Indoor,Outdoor
Feature :
High Contrast
Screen dimension :
Customized
Tube chip color :
Full Color
Display function :
Video
Description

About us

Shenzhen Reiss Optoelectronics Technology Co., Limited, established in 2004 located in Shenzhen China, is a professional LED display manufacturer and solution provider with technical and service over 10 years' experience. We strive to become a trendsetter in the LED industry by offering quality, custom and durable products to customers worldwide.

P1.875 Indoor HD LED Display Feature:

1) 480*480mm High Precise Die-Cast Aluminum Cabinet.
2) 14 bit color depth and up to 3840hz refresh rate.
3) 284,442pixel per sqare meter , high definion LED Display make it finest display quality.
4) Black SMD1515 and pure black module mask make it higher contrast rate.
5) light wieght 6kg/cabinet, thickless assemble gaps, Easy to Install.


P1.875 Indoor High Definition LED Display Application:
1. Indoor high definition LED Display
2. Indoor HD Rental LED Display Screen
3. Indoor HD Advertising LED Sign

P1.875 Indoor HD LED Display Specification:

LED Lamp Specification
Color
Package
Intensity
Viewing Angle
Wavelength
Testing Condition
Red
SMD1515
45-65mcd
120°
620-625nm
25℃,10mA
Green
SMD1515
120-200mcd
120°
516-530nm
25℃,5mA
Blue
SMD1515
20-40mcd
120°
465-475nm
25℃,5mA
Module Parameter
Pixel Pitch
1.875mm
Pixel Configuration
SMD1515
Density
284,442 pixels/㎡
Module Resolution
128pixel(L) *128pixel(H)
Module Dimension
240mm(L) * 240mm(H) * 18mm(D)
Driving Mode
Constant current, 1/32 duty
LED Cabinet
Module Quantity in a Cabinet
2(L) *2(H)
Cabinet Dimension
480(L)*480(H)* 80(D)mm
Cabinet Resolution
256(L) * 256(H)
Cabinet Material
Die-cast aluminum;
Cabinet Weight
≈6KG
Electricity Parameter
Optical Ratings
Brightness
≥1000 cd/㎡
Viewing Angle
120°(Horizontal)； 120°(Vertical)
Best Viewing Distance
≥1m
Gray Grade
14 bits
Display Color
4.4 trillion Colors
Brightness Adjustment
100 grades by software or automatically by sensor
Operation Power
AC100-240V 50-60Hz Switchable
Max. Power Consumption
900 W/㎡
Avg. Power Consumption
320W/㎡
control system
Frame Frequency
≥60Hz
Refresh Frequency
≥3840Hz
Input Signal
Composite Video, S-video, DVI, HDMI, SDI, HD-SDI
Control Distance
100m(Ethernet cable);
20KM(optical fiber cable)
Support VGA Mode
800*600, 1024*768, 1280*1024, 1600*1200
Color Temperature
5000—9300 adjustable
Brightness Correction
Pixel by pixel, module by module, cabinet by cabinet
Reliability
Working Temperature
-20～+60 ºC
Storage Temperature
-30～+70 ºC
Working Humidity
10%～90% RH
Lifetime
100,000 hours
MTBF
5000 hours
Continuous Operating Time
≥72 hours
Protection Grade
IP31
Out-of-Control Pixel Rate
≤0.01%
