P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
Specifications
Certification :
CE ROHS FCC EMS
Place of Origin :
Shenzhen
Delivery Time :
5-8
Brand Name :
Reiss
Model Number :
RSIN-P2.5
MOQ :
1
Price :
Negotiable
Usage :
Indoor
Tube chip color :
Full Color
Display function :
Video
Warranty :
3 Years
Application :
Advertising
Life span :
100000hours
Description
Full Color P2.5 LED Display
Main
Model
CN-P2.5-32S
Module
Pixel pitch(mm)
2.5
LED Lamp Model
SMD2121
Module Size(W*H)
160*160 mm
Module Size(W*H)
6.3*6.3 inch
Module Resolution(W*H)
64*64
Driving Mode
Constant drive
Scan Mode
1/32
Pixel configuration (R,G,B)
1R,1G,1B
Color temperature (K) :
3200-9300
Grey scale/colors
256levels of each color(RGB)/16.7M colors
Cabinet
Standard Cabinet Size(mm)
480*480*60
(W*H*T)
Cabinet Resolution(W*H)
192*192
Cabinet Module Number
9PCS
IP Grade
IP31
Cabinet Weigh(kg)
5.5
Cabinet Material
Die Casting Aluminum
Display
Best Viewing Distance(m)
2.5-50
Pixel Density (dot/m2)
160000
Brightness(cd/m2)
≥1200
Power Max Consumption (W/m2)
≤1200
Power Average Consumption (W/m2)
400
View angle
H:160; V:160
system Specification
Control host (CPU) :
Pentium4 or above
Operating system:
WIN98/2000/NT/XP
Control method
Synchronous display with control PC by DVI
Control System
Linsn, Nova-star, Colorlight or as you required
Display Content
Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
Interface definition
HUB75
Frame Frequency
≥60Hz
Refresh frequency
1920HZ/3840HZ
Transmission Distance
Multi mode fiber <500m, single mode fiber <30km,internet cable
Operation Parameter
Working Voltage
AC220±10% 50Hz/AC110±10% 60Hz
storage Temperature
35℃～+85℃
Working Temperature
-20℃～+60℃
Humidity
10%-95%
Life Span Time
≥100000 hours
MTBF
≥5,000hours
Screen Plainness
＜±1mm
Blind Spot Rate
＜0.0001
Certificate
CE, RoHS, FCC

P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation

P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation

P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation

P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation

P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation

P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation



P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation

P2.5 Indoor LED Video Panel Rental Low Attenuation Fast Heat Dissipation
