HD Full Color P3mm Outdoor LED Display Board Waterproof IP65
HD Full Color P3mm Outdoor LED Display Board Waterproof IP65
HD Full Color P3mm Outdoor LED Display Board Waterproof IP65
HD Full Color P3mm Outdoor LED Display Board Waterproof IP65
HD Full Color P3mm Outdoor LED Display Board Waterproof IP65
HD Full Color P3mm Outdoor LED Display Board Waterproof IP65
HD Full Color P3mm Outdoor LED Display Board Waterproof IP65
HD Full Color P3mm Outdoor LED Display Board Waterproof IP65
Specifications
Brand Name :
CRTOP
Model Number :
P3mm
Certification :
CE/CCC
Place of Origin :
CHINA
Product name :
Lighting Pole LED Display
PITCH :
3mm
Specification :
Waterproof / HD / Full color
Module resolution :
64 (W)* 64 (H)
Control distance :
Gigabit Ethernet cable: 100 meters, Optical fiber: 10 kilometers
Refresh rate :
≥ 1920-3840 Hz
waterproof :
IP65
brightness :
≧5000cd
cabinet size :
767*1352mm
Description

HD Full Color P3mm Outdoor LED Display Board Waterproof IP65

Full Color Lighting Pole P3mm LED Display for street road Advertising

Product Advantages :

1 . High definiton , high brightness 6500nits .

2 . Automatic brightness adjustment .

3 . Outdoor dust-proof and IP65 waterpoof .

4 . Intelligent temperature control .

5 . Remote control management .

6. Box size 767mm*1352mm, weight is only 15.8kg;

7. Excellent heat dissipation performance, overall waterproof design, the use of gold plated connector, stable, safe and reliable products.

parameters:

project parameter

BASIC PARAMETER

 pixel pitch 3 mm
pixel structure 1R1G1B
pixel density 111111 /m 2
Module resolution 64(W)* 64 (H)
Module size 192mm * 192mm _
Box size 768X768

OPTIC PARAMETER

 Single point luminance, chromaticity correction have
white balance brightness ≥ 5 0 00cd/㎡
color temperature 3200K—9300K adjustable
Horizontal viewing angle ≥ 120°
vertical viewing angle ≥ 120°
Visible distance ≥8 meters
Brightness uniformity ≥97%
Contrast ≥ 5 000:1

PROCCESSING PARAMETER

 Signal processing bits 16 bits*3
grayscale 16Bit
control distance Gigabit Ethernet cable: 100 meters, Optical fiber: 10 kilometers
drive mode High gray-scale constant current source driver IC
frame rate ≥ 60HZ
refresh rate ≥ 1920 Hz
way to control Synchronize
Brightness adjustment range 0 to 100 stepless adjustment

OPERATION PARAMETER

 Continuous working time ≥72 hours
Typical life 50,000 hours
Protection class Front IP65, back IP43
range of working temperature -20℃ to 50℃
Operating humidity range 10 %- 80% RH non-condensing
Storage temperature range -20 ℃ to 60 ℃

ELECTRIC PARAMETER

 Operating Voltage DC 5V
Power Requirements AC: 220×(1±10%)V, 50×(1±5%)Hz
Maximum power consumption 8 5 0W/ ㎡
Average power consumption 350W/ ㎡

HD Full Color P3mm Outdoor LED Display Board Waterproof IP65HD Full Color P3mm Outdoor LED Display Board Waterproof IP65HD Full Color P3mm Outdoor LED Display Board Waterproof IP65HD Full Color P3mm Outdoor LED Display Board Waterproof IP65HD Full Color P3mm Outdoor LED Display Board Waterproof IP65

After-sale service

Rest assured to buy it and feel free to contact us if you have any problems of this product .
