P3.91mm 4500cd Outdoor Rental LED Screen Vedio Wall Display
P3.91mm 4500cd Outdoor Rental LED Screen Vedio Wall Display
P3.91mm 4500cd Outdoor Rental LED Screen Vedio Wall Display
P3.91mm 4500cd Outdoor Rental LED Screen Vedio Wall Display
P3.91mm 4500cd Outdoor Rental LED Screen Vedio Wall Display
P3.91mm 4500cd Outdoor Rental LED Screen Vedio Wall Display
Specifications
Brand Name :
CRTOP
Model Number :
P3.91mm
Certification :
CE/FCC/ETL
Place of Origin :
CHINA
Supply Ability :
1000m²/month
pitch :
P3.91mm
material :
die cast aluminum cabinet
application :
outdoor rental
brightness :
4500cd
contrast ratio :
3000:1
view angle :
120º
install :
fast easy to install and uninstall
waterproof :
IP65
characteristic :
Arc, corner and various creative shapes
Description

P3.91mm 4500cd Outdoor Rental LED Screen Led Vedio Wall Display

private aluminum die cast cabinet outdoor P3.91mm rental led display led vedio wall

Rental led display,led wall parameter:

1. The overall use of frame-type visual design, the combination of the scattered and orderly appearance of the box, the hidden upper handle and the integrated power box , not only improves the operating experience, but also forms a more differentiated brand symbol characteristics. It has a great sense of space and visual tension in the state, giving people the product characteristics of firmness, stability and strong operability

2. giving people the product characteristics of firmness, stability and strong operability

3. the standard box can achieve 5° inner arc without adding custom locks or box assembly parts , providing a variety of possibilities for on- site design

4. Both the hoisting lock and the left and right locks can be quickly connected and disassembled;

project parameter

BASIC PARAMETER

 pixel pitch 3.91 mm
pixel structure 1R1G1B
pixel density 65410 / m2
Module resolution 64 (W)* 64 (H)
Module size 250mm*250mm
Box size 500mmX500mm

OPTIC PARAMETER

 Single point luminance, chromaticity correction have
white balance brightness ≥4500cd/㎡
color temperature 3200K—9300K adjustable
Horizontal viewing angle ≥ 120°
vertical viewing angle ≥ 120°
Visible distance ≥8 meters
Brightness uniformity ≥97%
Contrast ≥3000:1

Proccessing performace

 Signal processing bits 16 bits*3
grayscale 16Bit
control distance Gigabit Ethernet cable: 100 meters, Optical fiber: 10 kilometers
drive mode High gray-scale constant current source driver IC
frame rate ≥ 60HZ
refresh rate ≥1920 Hz
way to control Synchronize
Brightness adjustment range 0 to 100 stepless adjustment

Operation parameter

 Continuous working time ≥72 hours
Typical life 50,000 hours
Protection class IP 65
range of working temperature -20℃ to 50℃
Operating humidity range 10 %- 80% RH non-condensing
Storage temperature range -20 ℃ to 60 ℃

Electric parameter

 Operating Voltage DC 5V
Power Requirements AC: 220×(1±10%)V, 50×(1±5%)Hz
Maximum power consumption 80 0W/ ㎡
Average power consumption 3 6 0W/ ㎡

PITICH:

indoor P2.604 P2.97 P3.91

Outdoor P2.97 P3.91 P4.81

Module size:250x250mm

Box size: 500*500mm

P3.91mm 4500cd Outdoor Rental LED Screen Vedio Wall DisplayP3.91mm 4500cd Outdoor Rental LED Screen Vedio Wall Display
