Specifications
Model Number :
EV-62-16AC
Certification :
CE/TUV/ROHS/FCC
Place of Origin :
CHINA
Brand Name :
EVCOME
MOQ :
2 pcs
Delivery Time :
8-10days
Payment Terms :
L/C,D/A,D/P,T/T
Supply Ability :
500000 PIECE PER MONTH
Price :
negotiation
Rated power :
3.5KW-7KW
Input Voltage :
80-265V 50Z(1-P)
Output Voltage :
80-265V AC 16-32A
Chaging Interface Type :
IEC 62196-2/SAE J1772/GBT 20234
Material :
ABS+PC
Cables Length :
5 Meters(Custom)
Operatig Temperature :
-30℃-120℃
Relative Humidity :
5%-95% non-condensing
Cables size :
3*6MM² * 0.75MM²
Weight :
3kg
Equipment dimension :
210*85*48mm ( L*W*H )
Description

Products Description

Input & Output
Input voltage / Output voltage
220V
Output current
8A/10A/13A/16A Ajutable
Max power
3.6kw/7kw
Input frequency
50Hz
Standby power consumption
<3W
Charging interface type
TYPE 1(SAE J1722), TYPE 2 (IEC 61851),GBT(20234)
Protection
Over-voltage protection
Yes
grounding protection
 Yes
under-voltage protection
 Yes
over-temperature protection
 Yes
overload protection
 Yes
low-temperature protection
 Yes
earth leakage protection
 Yes
lightning protection
 Yes
Working environment
Applicable scene
Indoor / Outdoor
Operating temperature
-30℃ ~ +50℃
Height above sea level
<2000m
Operating humidity
5% ~ 95%, non-condensation
Protection level
IP65
Cooling method
Natural cooling
MTBF
100,000 hours
Special protection
UV protection design
Structure Appearance
 Certificate
Equipment dimension
210*85*48mm ( L*W*H )
 CE UKCA
Installation method
Portable Ev Charger
 ROHS
Wiring method

Bottom enter&out
Equipment weight
3kg
Length 5m or customized

EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234

EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234

EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234

EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234EVCOME Ev Charger Portable (220V 3.5KW 7KW) Max 16A Ajutable OEM ODM With SAE J1772 IEC 62196 GBT 20234

Our Service

Customer Service

★ We provide very professional product consultation and introduction to fully match your needs

★ 24-hour customer service team, ready to provide you with consultation and service

★ All customers will get one-on-one service.

Customized Service

★We offer very flexible customization services like OEM/ODM

★OEM includes color, logo, outer packaging, cable length, etc

★ODM includes function setting, new product development, etc.

After Sales Service

★We offer a one-year quality guarantee period for our products

★We have a very professional team to solve all the problems encountered in the process of use, they will be at your service 24 hours

Drop Shipping

★We have our own warehouses overseas, making delivery more convenient and faster
