3 Way Trunnion Mounted Ball Valve , Flanged Forged Steel Ball Valve
3 Way Trunnion Mounted Ball Valve , Flanged Forged Steel Ball Valve
Specifications
Brand Name :
OEM
Model Number :
Trunnion Mounted Ball Valve
Certification :
ISO 9001
Place of Origin :
Shanghai , China
MOQ :
Negotiation
Price :
negotiation
Payment Terms :
T/T advance or L/C at sight
Supply Ability :
90,000pcs per month
Delivery Time :
usually within 35 days after received your payment
Packaging Details :
Usually packing by plywood case suit for sea delivery
Product Name :
Trunnion Mounted Ball Valve
Type :
Trunnion Mounted
Size :
DN15 ~DN100
Temperature :
-20~140 C
Body :
brass Nickel plated
Ball :
brass Nickel plated
Description

3 Way Trunnion Mounted Ball Valve , Flanged Forged Steel Ball Valve

Trunnion Mounted Ball Valve Specification

- Nominal diameter: 1/2”-25”

- Applicable Temperature: -29℃～425℃(steel) -40℃～550℃(stainless steel)

- Nominal pressure: 150lbs, 300lbs, 600Lb,900lbs,1500lbs PN16/25/40/64/100/160, JIS 5K /10K/20K

- Applicable Medium: water ,gas,oil,and other causticity medium.

Trunnion Mounted Ball Valve Applications Standard

- Manufacture standard : API 608/ DIN/ BS/JIS

- Face to face dimension: ANSI B 16.10,API 6D/ DIN/ BS/JIS

- Flange dimension: ANSI B 16.5 MSS-SP-44/ DIN/ BS/JIS

- Test: API 598 API 6D/ DIN/ BS/JIS

Trunnion Mounted Ball Valve Materials of Construction


Nut Carbon Steel IS 1367
Washer Carbon Steel IS 1367
Lever Carbon Steel IS 2062
Body & Gland Nut Forged Brass IS 6912 Gr. FLB
Gland Packing PTFE BS EN 12086-1
Ball Forged Brass IS 6912 Gr. FLB
Body Seat Ring PTFE BS EN 12086-1
Bonnet Forged Brass IS 6912 Gr. FLB

Trunnion Mounted Ball Valve Sizes / Dimensions


3/8 10 47 3/8" 37 90
1/2 15 50 1/2" 40 90
3/4 20 58 3/4" 43 120
1 25 67 1" 51 120
1 1/4 32 76 1 1/4" 65 154
1 1/2 40 87 1 1/2" 72 154
2 50 104 2" 80 170
2 1/2 65 139 2 1/2" 102 250

Trunnion Mounted Ball Valve Technical Specification

Nominal pressure(Mpa)

PN

2.5,4.0,6.4

Strength testing pressure(Mpa)

PT

3.8,6.0,9.6

Low pressure seal test(Mpa)

　

0.6

High pressure seal test(Mpa)

　

3.0,4.8,7.6

Applicable medium

water, oil, gas, nitric acid, acetic acid

Applicable temperature

-40～180℃

Floating Ball Valve Feature:

- Reliable Seal Structure

The seat is made of PTFE. Because the contact area between seat and the ball will

becomes more high with rising of pressure of the middle cavity,

Small Resistance ball valve has the smallest resistance of all the valve, in the case

of reduced bore, the resistance is little still.

- Prompt switch

The ball valve circumrotates in 90°,It work quickly to open or close.

Test Pressure

Test Item

Shell Test

Seal Test

Back Seal Test

Air Seal Test

Medium

Water

Air

Unit

MPa

Lbf/in2

MPa

Lbf/in2

MPa

Lbf/in2

MPa

Lbf/in2

Pressure (Class)

150

3.1

450

2.2

315

2.2

315

0.5-0.7

60-100

300

7.8

1125

5.6

815

5.6

815

400

10.3

1500

7.6

1100

7.6

1100

600

15.3

2225

11.2

1630

11.2

1630

900

23.1

3350

16.8

2440

16.8

2440
