1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel
Specifications
Brand Name :
Shine Abrasives
Model Number :
Resin Bond Diamond Wheels
Certification :
ISO
Place of Origin :
China
MOQ :
2 pcs
Price :
FOB
Payment Terms :
L/C, T/T
Supply Ability :
10000 pcs in one week
Delivery Time :
5 working days
Packaging Details :
one in one paperbox
Size :
Required,100D-20H-4W-10X
Hardness :
Standard,Superhard Diamond,as required
Shape :
Flat-Shaped,flat
Abrasive :
diamond,Super abrasive,CBN
Viscosity :
good,as required
Bonding agent :
Resin,Vitrified
Application :
Diamond Wheel For CNC Tool,other decoration
Bond :
Resin,metal
Usage :
sharpening,grinding
Product name :
Diamond Grinding Wheel,Resin bond diamond grinding wheel for carbide
Grit :
24-320#
Color :
black and red,depends on grit number
Material :
Diamond,cbn,Rsin and diamond
Name :
Resin bond diamond grinding wheels for tungsten carbide,Vitrified CBN Diamond Grinding Wheel Manufacturer,abrasive grinding wheel
Type :
Flat,Resin diamond grinding wheel for Carbide,Grinding Tools
Body material :
Aluminum or steel
Abarasive material :
Diamond
Thickness :
5~300mm
Bonding :
rubber,resinoid,vitrified
Description

2023 1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel.

The flat resin diamond grinding wheel is mainly used for cylindrical grinding and cutting edge processing of cemented carbide.
Resin bond diamond grinding wheel is suitable for grinding metal and non-metal hard and brittle materials with low iron content,such as cemented carbide,high alumina porcelain, optical glass, agate gemstone, semiconductor material, ceramics, stone, etc.

Product Description:

Resin Bond Diamond Grinding Wheel is the most common choice in Diamond and CBN super-abrasive wheels. It forms a bond structure that keep the wheel sharp cutting, super surface finish, efficient grinding and less heat generating. The most important is that it is very cost effective. It is more competitive than Vitrified bond and Metal Bond. So it is broadly applied in the grinding industries.

Type 1A1 Flat resin bond diamond grinding wheel
Concentration 50%, 75% 100% 125% 150%
Mesh 46#, 60#, 80#, 100#, 120# (coarse grinding);
120#, 150#, 180#, 200#, 240# (medium grinding);
280#, 320#, 400#, 500#, 600# (fine grinding);
800#, 1000#, 1200#, 1500#, 2000#, 3000# (polishing)
Material Synthetic Diamond / CBN Powder
Specification
( Specification sizes can be customized )		 D75-H10-T5-X10 / D150-H19-X5-T5 / D125-T10-X10- H20/31.75 / D100-T10-X10- H20/31.75
D175-H127-X4-T5 / D250-H40-X10-T3 / D300-H127-X10-T40 / D350-H127-T20-X10 / D400-H127-T40-X10 / D500-H203-X10-T32
Application Hard alloy, high alumina porcelain, optical glass, agate gemstone, semiconductor material, ceramics, stone, etc.

1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel

1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel

1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel

Features of Resin Bond Diamond Grinding Wheel

1. High grinding efficiency, relative low consumption while grinding;
2. Good self sharpness, small thermal power and seldom clogging, which can greatly reduce the incidence of burn while grinding;
3. With certain elasticity, it is good for improving the surface roughness of workpiece, which is mainly used for fine grinding, semi fine grinding, knife grinding, polishing and other processing;
4. Low temperature curing, short production cycle, relative simple equipment & supplying process; Also, since the resin has fluidity, it is easy to shaped as the wheel with complex surface.
