Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
Specifications
Brand Name :
Shine Abrasives
Model Number :
1A1
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
100 PCS per week
Delivery Time :
20 working days
Packaging Details :
1 pcs in one wooden box
Materials :
CVD Diamond and steel body
Bond :
Electroplated bond
Diameter :
120mm
HS Code :
8207901000
Description

Reverse Plated Dressers Diamond Form Rollers For Grinding Wheels

Shine Abrasives diamond form rolls are used to shape grinding wheels in automatically controlled CNC dressing operations,

profiling grinding wheels by moving the diamond form roll along the required contour. These dressers not only meet exacting precision demands but offer high economic efficiency.

Main sizes form of Shine Abrasives Reverse Plated Dressers Diamond Form Rollers For Grinding Wheels

Abrasive Material:Diamond Bond Type:Electroplated
Tolerance: H3 Diameter: 120mm
Bore:60mmH3 Wheel Weight:3.5kgs/PC
Thickness:55mm Body Material: Steel

Other standard sizes also are available as requested.

Features of Shine Abrasives Reverse Plated Dressers Diamond Form Rollers For Grinding Wheels

Reverse plated diamond dressers have gone through an electro-deposition process that is stable and unaffected by shrinkage,

which results in rotary diamond dressers of exceptional accuracy.

With our reverse plated diamond dressers, diamond grain is actively involved in the dressing action, providing a long service life.

These types of rolls are used for intricate profiles and tighter tolerances where surface finish is important.

Advantages of Shine Abrasives Reverse Plated Dressers Diamond Form Rollers For Grinding Wheels

Quick transfer of difficult profile shapes onto the grinding wheel for series production.
Possibilities of automatizing the dressing process
Production of a large number of workpieces with very narrow and uniform tolerances
Low dressing costs for each workpiece due to the long using life of diamond profile rolls.
Minimization of reject rate due to reproducible manufacturing tolerances.

Package pictuers of of Shine Abrasives Reverse Plated Dressers Diamond Form Rollers For Grinding Wheels
Reverse Plated Dressers Diamond Form Rollers 120mm For Grinding Wheels
