WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives
WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives
WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives
WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives
WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives
WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives
Specifications
Brand Name :
Shine Abrasives
Model Number :
9/29
Certification :
ISO
Place of Origin :
CHINA
MOQ :
2 PCS
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
5000 pcs per week
Delivery Time :
5 working days
Packaging Details :
1 pcs in one paper box
Diameter :
5 inch 127mm
Bond :
Electroplated
Grit :
B151
Profile :
WM9/29
Tooth Spacing :
.875 TS
HS Code :
6804221000
Description

5'' 9/29 .875 TS 9° CBN Sharpening Wheel For Wood Band Saw Blades

Shine Abrasives 5'' diameter CBN wheels for Wood Mizer 9/29 profile band saw blades sharpening

10/30 profile is the very popular band saw blades. 9/29 is usual also called 9° profile.

For band saw with tooth spacing is 7/8'=22.22mm. the wheel thickness is 22.22mm

the wheel bore sizes are usual 12.7mm of 1/2 inch.

CBN abrasive can withstand a high temperature of 1250-1350 degrees Celsius, which is higher than the heat resistance of diamond at 800 degrees Celsius; when grinding and cutting iron materials, there will be no sticky chip phenomenon, and when grinding hardened steel, high vanadium and high speed Metal materials that are sensitive to grinding temperature, such as steel and aluminum high-speed steel, are the most ideal grinding wheels for them.

The drawing of Shine Abrasives 5'' 9/29 .875 TS 9° CBN Sharpening Wheel For Wood Band Saw Blades

WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives

The size form of Shine Abrasives 5'' 9/29 .875 TS 9° CBN Sharpening Wheel For Wood Band Saw Blades

Abrasive Material:CBN Bond Type:Electroplated
CBN Grit:100# Wheel Diameter:5''=127mm
Wheel Bore:12.7m Wheel Weight:2.0kgs/PC
Wheel Thickness:22.2mm Body Material: Steel

Other sizes also are available as requested.

Package of Shine Abrasives 5'' 9/29 .875 TS 9° CBN Sharpening Wheel For Wood Band Saw Blades
Single wheel in one black color paper box as below picture.
10PCS Wheels are in one export carton.

WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives

Features of Shine Abrasvies 5'' 9/29 .875 TS 9° CBN Sharpening Wheel For Wood Band Saw Blades

Extreme hardness
Strength
Abrasion resistance
Superior thermal and chemical resistance.

The bonds kinds of CBN grinding wheels.

01:Electroplated bond CBN wheel.

02:Metal bond CBN wheel.

03:Resin bond CBN wheel.

04:Vitrified bond CBN wheel.

Application picture for reference

WM9/29 Profile Cbn Wheels For Sharpening B151 Shine Abrasives
