6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding
6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding
6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding
6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding
6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding
6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding
Specifications
Brand Name :
Shine Abrasives
Model Number :
6A2C Cup
Certification :
ISO
Place of Origin :
CHINA
MOQ :
2 PCS
Price :
Negotiate
Payment Terms :
Negotiate
Supply Ability :
10000 pcs per week
Delivery Time :
5 working days
Packaging Details :
1 pcs in one paper box
Shape :
6A2C Cup
Diameter :
6 inch 150mm
Bond Type :
Resin
Grit Size :
150 Grit
Diamond Rim Size :
20x3mm
Country Of Origin :
China
Description

Resin Bond Diamond Cup Wheel 150mm For Carbide Grinding Or Sharpening

Shine Abrasives Resin Bond Diamond Cup Wheel 150mm is suitable for grinding carbide materials.

Grinding the main edges relief angles of carbide saw blades and all kinds of carbide tools
Sharpening Carbide Circular saw Blades or other carbide tipped tools.
Re-Grinding all kinds carbide tools.

The drawing of Shine Abrasives Resin Bond Diamond Cup Wheel 150mm For Carbide Grinding Or Sharpening

6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding

Specifications of Shine Abrasives Resin Bond Diamond Cup Wheel 150mm

For Carbide Grinding Or Sharpening

Abrasive Material:Diamond Bond Type:Resin
Diamond Rim Size:20x3mm Diamond Grit:150 grit,
Concentration:125% Wheel Diameter: 6inch 150mm
Wheel Thickness:25mm Wheel Bore: 1-1/4 inch/31.75mm
Wheel Type:6A2 Cup Wheel Weight:1.0kgs/PC

Question

How to dressing the resin bond super abrasives grinding wheels?

They are usual 2 methods to dressing the resin bond super abrasives grinding wheels.

1:

Dressing by the white aluminum oxide sticks for CBN wheels,

and silicon carbide sticks for diamond wheels, it's manual as below picture.

6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding

2:

Dressing by a silicon carbide abrasive wheel on a special device with a centrifugal brake.

Contacting with the grinding wheel, the truing wheel turns, due to braking, it slips relative to the grinding wheel,

“opening” its working surface and decreasing its run-out at the same time.

Like blow picture.

6A2C Cup Resin Bond Diamond Wheels 150mm For Carbide Grinding

The wheels are also dreessing by Diamond dresser sometimes.
