Long Warranty AC Portable Load Bank Economical With 220V Phase Voltage
Long Warranty AC Portable Load Bank Economical With 220V Phase Voltage
Long Warranty AC Portable Load Bank Economical With 220V Phase Voltage
Long Warranty AC Portable Load Bank Economical With 220V Phase Voltage
Specifications
Brand Name :
KAIXIANG
Model Number :
1000 KW
Certification :
ISO9001
Place of Origin :
HEBEI CHINA
MOQ :
ONE SET
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram, D/P
Supply Ability :
20 SETS ONE MONTH
Delivery Time :
ONE MONTH AFTER GET DEPOSIT
Packaging Details :
WOODEN CASE
Rated Voltage :
380 VAC
Installed Capacity :
Resistive load: 1010 kW
Control Power :
400VAC/50Hz, 3 phase 4 wire, 230V 1-phase
size :
1600*2400*2100 mm
Ambient Temperature :
-10℃～+50℃
Load Step :
1、2、2、5、10、20、20、50、100、200、200、200、200kW, min step load: 1kW
Description

Long Warranty And Economical 1000KW AC Load Bank Quality Tester

Product Description

AC Load Bank offers the most robust, high-capacity designs in the industry. It is setting the standard with intelligent operator controls, safety indication layouts, adjustable load step resolution, and lightweight designs. AC Load Bank is the perfect solution for regularly scheduled maintenance testing and commissioning of mission-critical standby emergency power systems.

Technical Parameters

Rating Voltage/Frequency380VAC/50Hz, 3 phase 4 wire, line voltage 380V, phase voltage 220V
Rated Load PowerResistive load: 1000kW
Installed CapacityResistive load: 1010kW
Load Step1,2,2,5,10,20,20,50,100,200,200,200,200kW, min step load: 1kW
PF(Power Factor)1
Load Tolerance (each step)±5%
Load Tolerance(overall)±3%
Display Precision0.5 class
Control Power400VAC/50Hz, 3 phase 4 wire, 230V 1-phase
Wire Connection

Load power supply input——Copper bar (star coupling)
Control power supply input——Connector-bar

InsulationF
Duty CycleContinuous
Casing Dimensions and Coolingabout 1600*2400*2100mm (length*width*height) Forced air cooling,Horizontal inlet air,Horizontal outlet air
WeightAbout 1500kgs/set
TransportationHoisting, there are lifting lug in top of casing
Casing ColorGrey(RAL7035)
Ambient Temperature-10℃～+50℃
Relative Humidity≤95%
Altitude≤2500 meter
Atmospheric Pressure86～106kPa
ContactorSchneider
FuseDELIXI
MCUINFINEON
Data processing softwareKaixiang(self-developed)
Alloy ResistanceKaixiang(self-developed)


Product Advantage

Inspection before delivery Strictly debug and inspect the load bank according to technical agreement and related standard, will not delivery until reach the required standard. User can send technicians to production base to accept goods.
Transportation Send goods to designated address safely
On-site service Send technicians to the real working place, assistant to assemble, debug, train, accept and attend the first formal testing

Application

Transformer manufacturing:Measuring the transformr's parameters include rated capacity,current ,voltage ,frequency,temperture-rise and noise and so on.
