Full Automatic AC Electronic Load Bank For Scheduled Maintenance Testing
Full Automatic AC Electronic Load Bank For Scheduled Maintenance Testing
Full Automatic AC Electronic Load Bank For Scheduled Maintenance Testing
Full Automatic AC Electronic Load Bank For Scheduled Maintenance Testing
Specifications
Brand Name :
KAIXIANG
Model Number :
AC440-468KVA
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
15 Sets per Month
Delivery Time :
Within 30 working days
Packaging Details :
Wooden Case for Load bank
Rating Voltage/Frequency :
440VAC/60Hz, 3 phase 4 wire,
Casing Color :
Grey（RAL7035）
Ambient Temperature :
-10℃～+50℃
Load Tolerance :
±5%
weight :
2500kg
PF :
0.8
Description

Full automatic 440V 468KVA Inductive Load Bank For Middle East

Product description

1. AC Load Bank offers the most robust, high-capacity designs in the industry.

2. It is setting the standard with intelligent operator controls, safety indication layouts, adjustable load step resolution, and lightweight designs.

3. AC Load Bank is the perfect solution for regularly scheduled maintenance testing and commissioning of mission-critical standby emergency power systems


Technical Parameter

Rating Voltage/Frequency 440VAC/60Hz, 3 phase 4 wire,
Voltage range 380v 50hz ±10%
Max Rated power

Apparent Power: 468.75kVA

Resistive Power: 375kW

Reactive Power: 281.25kvar
Load Resolution

Resistive Load: 25.50.100.200kw

Reactive load: 18.75.37.5.75.150kvar
PF(Power Factor) 0.8
Load Tolerance (each step) ±5%
Load Tolerance(overall) ±3%
Display Precision 0.5 class
Control Power 380VAC/50Hz,
Wire Connection

Load power supply input——Copper bar (star coupling)

Control power supply input——Connector-bar
Communication Interface RS485,
Casing Dimensions and Cooling about 2440*1250*1680mm (length*width*height) Forced air cooling,Horizontal inlet air,Vertical cooling
Weight About 2500kgs/set
Transportation Hoisting, there are lifting lug in top of casing
Casing Color Grey(RAL7035)
Ambient Temperature -10℃～+50℃
Relative Humidity ≤95%
Altitude ≤2500 meter
Atmospheric Pressure 86～106kPa
Contactor Schneider
Fuse DELIXI
MCU INFINEON
Data processing software Kaixiang(self-developed)
Alloy Resistance Kaixiang(self-developed)


Product Advantage

Professional technical team with more than 20 years design experience

Customized technical solutions meet customer’s individual requirements

Skilled workman insure the reliable assembly technology

Strict inspection procedures throughout the whole production flow

Prompt delivery & custom clearance make sure the customers receive the goods on time

Perfect after sales service create good user experience

Application

Assist shipyard in mooring test,sea trial test
Assist with the acceptance of the vessel generator test
Eliminate the carbon deposition of generator
As the generator loading system
Periodic running test for standby generator
