Electrical 500kw 50HZ Resistive Load Bank For Testing Output Power Of Generator
Electrical 500kw 50HZ Resistive Load Bank For Testing Output Power Of Generator
Electrical 500kw 50HZ Resistive Load Bank For Testing Output Power Of Generator
Electrical 500kw 50HZ Resistive Load Bank For Testing Output Power Of Generator
Specifications
Brand Name :
KAIXIANG
Model Number :
500KW
Certification :
ISO9001
Place of Origin :
HEBEI CHINA
MOQ :
1 SET
Price :
negotiable
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
100 SETS ONE MONTH
Delivery Time :
ONE MONTH AFTER GET DEPOSIT
Packaging Details :
WOODEN CASE
Rating voltage/frequency :
400VAC/50Hz, 4 wire, line voltage 400V, phase voltage 230V
Max Load Power :
500 KW
Dimensions :
About 1460*1980*1800mm L×W×H
Weight :
About 1000 kgs
Control Power :
Single voltage 220VAC 50Hz
Insulation :
F
Description

Load bank power 500kw 50HZ for testing the output power of generator

Product Description

The system can accurately test the output power and load capacity of various generator sets.The system consists of two parts of measurement and loading, including AC load bank, data acquisition system, automatic load and drop control system, cooling device, auxiliary control,PC software,and so on.The user can freely select local control or software control to operate the load bank.

Technical Parameter

Rating Voltage/Frequency 400VAC/50Hz, 3 phase 4 wire, line voltage 400V, phase voltage 230V
Rated Power Resistive load:500kW
Installed Capacity Resistive load: 500kW
Load Step 1,2,2,5,10,10,20,50,100,100,200kW, min step load: 1kW
PF(Power Factor) 1
Load Tolerance (each step) ±5%
Load Tolerance(overall) ±3%
Display Precision 0.5 class
Control Power Single voltage 220VAC 50Hz
Wire Connection

Load power supply input——Copper bar (star coupling “Y”)

Control power supply input——Connector-bar
Insulation F
Way of Working Continuous Working
Casing Dimensions and Cooling about 1460*1980*1800mm (length*width*height) Forced air cooling,Horizontal inlet air and vertical cooling
Weight About 1000kgs/set
Transportation Hoisting, there are lifting lug in top of casing, also the wheel casters can be provided
Casing Color Grey(RAL7035)or as you required
Workplace Outdoor
Ambient Temperature -10℃～+50℃
Relative Humidity ≤95%
Altitude ≤2500 meter
Atmospheric Pressure 86～106kPa

Product Advangent

We provide one year manufacturer limited warranty. All machine’s fault caused by the defects in material and workmanship of our generator produced by KAIXIANG is warranted, during the warranty period, KAIXING will offer technical support and sending parts for replacement if needed. The distributors of our products should examine the generators which have problem and feedback to us with related picture and products serial number.

Application:

It is used with Engine Generators, Battery Systems, UPS Systems, Inverters, Ground Power Units, Auxiliary Power Units, Aircraft Power Generators, Wind Generators, and Hydro Generators.
