1000 Watt Silicon Carbide Rod Heater High Temperature Heating SiC Rods
1000 Watt Silicon Carbide Rod Heater High Temperature Heating SiC Rods
Specifications
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
Spark Industry (Henan) Co., Ltd.
Delivery Time :
15 work days
Packaging Details :
WOODEN CASE
Mounting Type :
Horizontal
Wattage :
1000 watts
Terminal Connection :
Threaded stud
Type :
H-type
Features :
High thermal conductivity, low thermal expansion, excellent thermal shock resistance
Voltage :
240 volts
Material :
Silicon carbide
Heating Zone :
Single
Length :
12 inches
Application :
High temperature heating
Maximum Operating Temperature :
1400°C
Resistance :
1.5 ohms
Diameter :
1/4 inch
Shape :
Rod
Place of Origin :
China
Brand Name :
SONGYU
Description

H-type silicon carbide rod

After the rod passes through the rod holes on both sides (or up and down) of the furnace wall, it should rotate freely 360 degrees to prevent forced installation and knocking. Before installing the rod, an iron pipe with the same diameter as the rod can be used for trial installation.

The use of silicon carbide rods must be equipped with voltage regulators or controllable silicon voltage regulators, as well as voltage, current meters, and temperature automatic control instruments. During use, due to the oxidation of the rod, the resistance gradually increases. In order to maintain normal furnace temperature, the operating voltage should be increased. When the voltage reaches the maximum limit of the voltage regulator used but still cannot meet the requirements, the furnace can be stopped and the wiring method of the rod can be changed before continuing to use.

Mounting Type Horizontal
Wattage 1000 watts
Terminal Connection Threaded stud
Type H-type
Voltage 240 volts
Material Silicon carbide
Heating Zone Single
Length 12 inches
