1400C Silicon Carbide Elements SiC Silicon Carbide Rod Heater 220V-600V
1400C Silicon Carbide Elements SiC Silicon Carbide Rod Heater 220V-600V
Specifications
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
Spark Industry (Henan) Co., Ltd.
Delivery Time :
15 work days
Packaging Details :
WOODEN CASE
Product Type :
Heating Elements
Material :
Silicon Carbide (SiC)
Shape :
W Shape
Features :
High Temperature Resistance, High Thermal Conductivity, Long Service Life
Cold End Length :
100mm, 150mm, 200mm, 250mm, 300mm
Voltage :
220V, 240V, 480V, 600V
Power :
1500W, 2000W, 2500W, 3000W, 3500W, 4000W
Hot Zone Length :
200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm
Max Temperature :
1400°C
Density :
2.6g/cm³
Length :
300mm, 400mm, 500mm, 600mm, 700mm, 800mm, 900mm, 1000mm
Diameter :
12mm, 14mm, 16mm, 18mm, 20mm
Resistance :
1.2Ω, 1.4Ω, 1.6Ω, 1.8Ω, 2.0Ω
Thermal Conductivity :
120W/m·K
Place of Origin :
China
Brand Name :
SONGYU
Description

W Type SiC Heating Elements

Advantages of Silicon Carbide Heater

1. The temperature can reach up to 1500 ° C (surface temperature).

2. There are various shapes available, such as rod-shaped, U-shaped, W-shaped, single helix, and double helix, to meet your needs.

3. The size range is relatively large.

4. Generate high heat output per unit surface area.

Application of Silicon Carbide Heater

It can be widely used in sintering and heating elements for ceramics, magnets, glass, metallurgy, refractory materials, etc.

There are two different types of three-phase components: SGC (dumbbell type) and SGD (standard type).

These elements are self bonded silicon carbide formed by recrystallization of silicon carbide at high temperatures. It consists of three high-purity silicon carbide rods, with one end connected by a silicon carbide crossbar. SGC components are designed for vertical installation in standard float glass baths, while SGD components are designed for horizontal installation. They can be directly connected to a three-phase power supply and are a single-sided terminal type that allows terminals to be extracted from the furnace top.

Product Type Heating Elements
Material Silicon Carbide (SiC)
Shape W Shape
Features High Temperature Resistance, High Thermal Conductivity, Long Service Life
Cold End Length 100mm, 150mm, 200mm, 250mm, 300mm
Voltage 220V, 240V, 480V, 600V
