Hybrid PCB 10mil RO4350B And FR4 5 Layer PCB With Immersion Gold For 2.4 Ghz Antenna
Hybrid PCB 10mil RO4350B And FR4 5 Layer PCB With Immersion Gold For 2.4 Ghz Antenna
Hybrid PCB 10mil RO4350B And FR4 5 Layer PCB With Immersion Gold For 2.4 Ghz Antenna
Hybrid PCB 10mil RO4350B And FR4 5 Layer PCB With Immersion Gold For 2.4 Ghz Antenna
Hybrid PCB 10mil RO4350B And FR4 5 Layer PCB With Immersion Gold For 2.4 Ghz Antenna
Hybrid PCB 10mil RO4350B And FR4 5 Layer PCB With Immersion Gold For 2.4 Ghz Antenna
Specifications
Brand Name :
Bicheng
Model Number :
BIC-080.V1.0
Certification :
UL, ISO9001, IATF16949
Place of Origin :
CHINA
MOQ :
1PCS
Price :
USD9.99-99.99
Payment Terms :
T/T
Supply Ability :
5000PCS per month
Delivery Time :
8-9 working days
Packaging Details :
Vacuum bags+Cartons
Base material :
RO4250B+FR-4
Layer count :
5 Layer
PCB thickness :
1.0mm
PCB size :
159.12 x 39.78mm=1PCS
Solder mask :
Green
Silkscreen :
White
Copper weight :
Inner layer 35um, outer layer 18um
Surface finish :
Immersion gold
Description

5 Layer Hybrid PCB Built On 10mil RO4350B and FR-4 with Immersion Gold for 2.4 Ghz Antenna

(Printed circuit boards are custom-made products, the picture and parameters shown are just for reference)

Hello everyone,

Warm greetings!

Today we’re going to introduce a type of 5-layer PCB built on mixed RF material RO4350B and epoxy glass FR-4. It’s for the application of 2.4 Ghz Antenna. It's 1.0 mm thick with through holes. Green solder mask covers both sides and immersion gold on pads. They're fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 25 boards are packed for shipment.

Hybrid PCB 10mil RO4350B And FR4 5 Layer PCB With Immersion Gold For 2.4 Ghz Antenna

The above drawing is the stack-up. “Layer 2” is etched off and left 5 layers of copper on board.

Features and benefits

1) Signal integrity performance improved over the stack-ups with all FR4 board;

2) Quick CADCAM checking and free PCB quotation;

3) No MOQ, low cost for prototypes and small runs quantity;

4) IPC Class 2 / IPC Class 3 standard.

Hybrid PCB 10mil RO4350B And FR4 5 Layer PCB With Immersion Gold For 2.4 Ghz Antenna

Applications are wide, for example, consumer electronics, antenna WiFi, 8 port switch, embedded computer DC transformer, inverter auto, WiFi 4G router and temperature module etc

Parameter and data sheet

PCB SIZE 159.12 x 39.78mm=1PCS
BOARD TYPE Hybrid Multilayer PCB
Number of Layers 5 layers
Surface Mount Components YES
Through Hole Components YES
LAYER STACKUP copper ------- 18um(0.5oz)+plate TOP layer
RO4350B 10 mil (0.254mm)
Prepreg 0.12mm
copper ------- 35um(1oz) MidLayer 1
FR-4 0.152mm
copper ------- 35um(1oz) MidLayer 2
Prepreg 0.12mm
copper ------- 35um(1oz) MidLayer 3
FR-4 0.152mm
copper ------- 18um(0.5oz)+plate BOT layer
TECHNOLOGY
Minimum Trace and Space: 5 mil / 5 mil
Minimum / Maximum Holes: 0.4 mm / 5.0 mm
Number of Different Holes: 7
Number of Drill Holes: 81
Number of Milled Slots: 2
Number of Internal Cutouts: 0
Impedance Control: no
Number of Gold finger: 0
BOARD MATERIAL
Glass Epoxy: FR-4 Tg130℃, er<5.4; RO4350B Tg280℃, er < 3.8
Final foil external: 1 oz
Final foil internal: 1 oz
Final height of PCB: 1.0 mm ±0.1
PLATING AND COATING
Surface Finish Immersion gold (14.6% ) 0.05µm over 3µm nickel
Solder Mask Apply To: TOP and Bottom, 12micron Minimum
Solder Mask Color: Green, PSR-2000GT600D, Taiyo Supplied.
Solder Mask Type: LPSM
CONTOUR/CUTTING CNC Routing
MARKING
Side of Component Legend TOP and Bottom.
Colour of Component Legend White, IJR-4000 MW300, Taiyo brand
Manufacturer Name or Logo: Marked on the board in a conductor and leged FREE AREA
VIA Plated through hole(PTH), minimum size 0.4mm.
FLAMIBILITY RATING UL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension: 0.0059"
Board plating: 0.0029"
Drill tolerance: 0.002"
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.
