Wireless Matched Filter RF Shielded Test Enclosure 0.8GHz To 6GHz 70dB
Wireless Matched Filter RF Shielded Test Enclosure 0.8GHz To 6GHz 70dB
Wireless Matched Filter RF Shielded Test Enclosure 0.8GHz To 6GHz 70dB
Wireless Matched Filter RF Shielded Test Enclosure 0.8GHz To 6GHz 70dB
Wireless Matched Filter RF Shielded Test Enclosure 0.8GHz To 6GHz 70dB
Wireless Matched Filter RF Shielded Test Enclosure 0.8GHz To 6GHz 70dB
Specifications
Brand Name :
Jiaduoli
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100pcs/month
Delivery Time :
10-15 work days
Packaging Details :
Wooden box For Stainless Steel Pneumatic Rf Shielding Box
Product Name :
Automatic Rf Test shield box
Chipset :
0.8-6GHz
Application :
Wifi test
Shielding effect :
2.4GHz > -85dB 5.8GHz > -80dB
Frequecy :
0.8-6GHz
Box materia :
Stainless Steel
Description

Shield Box Enclosure Wireless Matched Filter Test Rf Shielded Enclosure

This rf faraday cage is an economical pneumatic single-layer shielding box, which is suitable for building modules and terminal tests in smartphones, WI-FI, wireless, smart grid equipment, automotive electronics, drones, smart homes, and other fields & Solution platform. The shield of test box is made of high-quality large-scale plate laser CNC cutting, sheet metal molding, electroplating, electrostatic spraying paint, assembly and commissioning, aging, testing, and other dozens of strict processes.

Rf Shielded Enclosure Function
* This EMI/RFI-shielded box has up to 70 dB reduction of RF signals up to 5 GHz. This makes the shielded box ideal for testing cellular handsets, RFID, Bluetooth, Zigbee, WiMax, WLAN or similar wireless devices.
* The box can be constructed in any size required.
* The box is well suited for the cases where the current state of an electronic device needs to be frozen by blocking all wireless contact with the outside world
* Many other shielded conduits are available on request. They may optionally also be added later.

Working frequency(GHz) 0.8～6Ghz
Shielding effect ≥70dB@2.4GHz/5.8GHz
Interface Type 1) 1*RS232(or VGA)+2*USB+1*RJ45+1*DC( Included into price)
2) 2*RJ45+2*USB+2*DC
3) 4*RJ45+2*USB
4) 1*RS232(or VGA)+2*USB+2*RJ45
5) 1*RF232+1*DB25
6) 1*AC+2*DC
6) 4*Air hole(Φ6 or Φ4)
7) 4*SMA
8) others: HDMI; DC terminal,etc;
Numbers of filters 3pcs,Exact type refer to below photo
Control method Touch switch control
Compatible with RS232 communication instructions
PLC online programming control (option)
Safety protection measures Magnetic ring, light sensor dual protection, ensure operational safety
Working temperature(℃) Normal temperature work
Working size(mm) (L)400x(W)400x(H)400mm
Appearance dimension(mm) (L)550x(W)515x(H)525mm

Rf Shielded Enclosure Features:

* Wireless communication test system
* For BT, WiFi, 3G, wireless test, RFID
* High level of shielded attenuation,up than 70dB
* Flexible operation in Lab and production line
* R&D, custom design& size
* Box can be equipped with shielded power filters for power connection in the box while still blocking all wireless signals.
* By default, it comes with 4 shielded SMA penetrations, 12 VDC, data line filter (RJ45), 2 times USB and a VGA penetration.
The Pneumatic auto shield box filter interface is suitable for wireless terminal testing such as routers, set-top boxes, drones,wireless headsets, wireless water meters, mobile phones, etc. It has the following characteristics: Aluminum alloy material,sturdy and durable, excellent shielding performance; Modular design, more humane characteristics, users can choose different interface combinations according to their needs
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
4
433(W)*440(D)*313(H)
540(W)*562(D)*395(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
2
346(W)*386(D)*278.5(H)
470(W)*534(D)*392(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
6
420(W)*400(D)*310(H
526(W)*517(D)*449(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
4
450(W)*450(D)*350(H)
587(W)*565(D)*464(H
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
Out: 4P
Inner: 2P
495(W)*495(D)*245(H)
585(W)*595(D)*325(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
2
325(W)*298(D)*280(H)
410(W)*415(D)*370(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
6
696(W)*426(D)*300(H)
818(W)*562(D)*400(H
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
2
325(W)*298(D)*231(H)
410(W)*406(D)*321(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
5
546(W)*566(D)*400(H)
690(W)*715(D)*514(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
4
p:495(W)*595(D)*325(H)
own:495(W)*595(D)*60(H)
600(W)*705(D)*405(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
10
433(W)*440(D)*313(H)
515W)*550(D)*525(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
4
400(W)*400(D)*400(H
515W)*550(D)*525(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
2
540(W)*500(D)*405(H)
720(W)*725(D)*525(H)
RS232 (or PLC )
0.8~6
≥ 70dB @2.4GHZ ≥ 70dB @5.8GHZ
10
434(W)*447(D)*400(H)
525(W)*600(D)*555(H)

Our Service:

  • Customized design: offering whatever size you need according to your DUT.
  • No MOQ: Our OEM/ODM starts at as few as 1-10 pcs of one design to fit your needs.
  • Fast Delivery: Delivering the products within 3 business days for some models.

FAQ:

Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 3 days if the goods are in stock. or it is 15-20 days against the quantity if the goods are not in stock.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample with charge

Q: What is your warranty?
A: One year
