5050wwa led smd 3 white color chips cct dimmable led
5050wwa led smd 3 white color chips cct dimmable led
Specifications
Place of Origin :
Shenzhen
Brand Name :
LC
Certification :
CE,RoHS
Model Number :
LC-5050WWA
Size :
5.5x5.0x1.6mm
LED Chip :
Epistar
Color :
amber+warm white+blue white in one 5050 smd led
MOQ :
1000pcs
Price :
0.065usd/pcs
Packaging Details :
Anti-static Bags+carton bag
Delivery Time :
3days
Payment Terms :
Paypal,TT,Western Union
Supply Ability :
50000pcs/Day
Description

5050wwa led smd 3 white color chips cct dimmable led

These SMD LEDs are packaged in the industry standard CLPP6 package. These high-reliability and high-brightness LEDs are designed to work in a wide range of environmental conditions and are ideally suited for use in illumination applications. Their wide viewing angle makes these LEDs ideally suited for channel letter, or general backlighting and illumination applications. The flat top emitting surface makes it easy for these LEDs to mate with light pipes. All components are produced by packing high-performance LED chips and silicon resin with proprietary phosphors.

1. Features and Benefits

. Ideal for LED lighting application to avoid multi-shadows

. Higher heat conductivity for better thermal management

. Provide variable and innovative array LED layout designs and combinations

. Resuce the initial development cost and time

. High lumen-performance per dollar cost

. Lead free reflow solder compatible with RoHS compliant

2. Applications

. Light Strip

. Channel Letter

. Backlight

5050wwa led smd 3 white color chips cct dimmable led

5050wwa led smd 3 white color chips cct dimmable led

5050wwa led smd 3 white color chips cct dimmable led
