P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply
Specifications
Brand Name :
Shichuangxinke
Model Number :
SCXK-P2.5
Certification :
CE RoHS FCC CCC TUV UL
Place of Origin :
China ,Guang Dong
MOQ :
3 square meters
Price :
USD1900-2100 per square meters
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000sqm per month
Delivery Time :
7-10 working days after deposit payment received
Packaging Details :
wooden box flight case, wooden case, carton, it is up to you.
Resolution/mm :
2.5
Pixel Density :
160000
Scanning Mode :
1/16 scanning
Control system :
LSN
Module size :
160*160MM
certificates :
CE RoHS FCC CCC UL
application :
stadium,airport,shopping mall,street advertising
working voltage :
DC5V
warranty :
3-5 years
Description

P2.5 Advertising SMD LED Screen Resolution64*64mm Indoor Ip34 Strong Power Supply

Quick Details

1) Video display for advertising
2) News, sports, concerts live broadcasting
3) Stage background
4) Time, schedule, text message display
5) Dynamic display of logos, text, video

FAQ

Q1: How to help customers choose the right monitor?

A1: (1) Specific application scenarios
(2) Viewing distance requirement
(3) Brightness requirement of the monitor
(4) Specific installation environment
(5) Budget and cost control

Question 2: How is your technical support?

A 2: Professional engineers are on standby to provide guidance and on-site technical support as needed.

Q 3: What is the control system?

A3: For synchronous control: Nova, Linsn or Mooncell control systems.
Asynchronous control: Onbon or Xixun control system.

Q4: How long is the warranty for your LED displays?

A 4: We provide 2 years warranty and lifetime technical support for our LED display products.

Q5: What are your payment terms?

A 5: Our payment method is T/T 30% as deposit and the balance before delivery.

Specifications :

outdoor SMD P4
Resolution/mm 2.5
Pixel configuration 1R1G1B
Pixel density/pixels/m² 160000/m²
Module resolution 160*160
Module size/mm 480*480MM
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/16 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

after-sale service:


1. Lifetime free maintenance and upgrading.
2. Complaint response time not more than 24 hours; provide maintenance guidance and problem solutions within 48 hours. 3.
3. Customer satisfaction tracking report.
4. free training for technicians
5. Provide a full set of documents free of charge, including installation guide, software operation manual, simple maintenance manual and control system software CD-ROM.
Manuals and control system software CD-ROM, etc.
6. Specialized services for large-scale projects, such as stadiums, exhibitions, plazas, etc.

P2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power SupplyP2.5 Rental Advertising SMD LED Screen Resolution 64*64mm Indoor Ip34 Power Supply

Welcome to visit our website and inquire us more info,waiting for you all the time!!!
