Specifications
Brand Name :
SCXK
Model Number :
SCXK-P5
Certification :
CE ,RoHS, FCC.CCC,SAA ,TUV ,UL
Place of Origin :
China(Mainland)
MOQ :
Negotiations
Price :
Negotiations
Payment Terms :
T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability :
5000sqs/month
Delivery Time :
7-10 working days after payment
Packaging Details :
Wooden and flight cases,it's up to you.
Product name :
LED Billboards
Color :
Full color,RGB LED Display
LED chip :
Epistar
Waterproof :
IP65
Module size :
320*160mm
Cabinet material :
Iron
Scan mode :
1/8
Resolution :
32*32
Brightness :
≥7500cd/sq
Warranty :
3-5years
Pixel density :
40000dots/sq
Indoor options :
P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P10...
Description

SMD Outdoor P5 Iron Cabinet LED Billboards Module320*160mm 1/8 Scan High Resolution

What we do?

We are a leading manufacturer and provider of technical solution of full color indoor an outdoor ledisplay,rental LED display, led modules where in Shenzhen ctiy,Guangdong province,China.

Why choose us?

1. Professional team and good after-sales service.

2. Commitment to high quality and low price of products.

3. Fast delivery after payment.

4. free technical support.

5. if any problem occurs, we will reply within 3-4 hours.

Specifications :

outdoor SMD P5 Full Color LED Billboards
Resolution/mm 5
Pixel configuration 1R1G1B
Pixel density/pixels/m² 40000/square meter
Module resolution 32x32mm
Module size/mm 320x160mm
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Competitive advantages:
1, P5 SMD outdoor full color LED display screen brightness and color uniformity;
2, Full color P5 LED screen adopts full black color LED chip;
3, indoor full color LED video screen contrast ratio up to 1000:1, response to the true color of the content;
4,Using Sum driver IC, high refresh frequency, high gray level;
5, Horizontal and vertical 140 degrees of large viewing angle;
6, P4 LED display high resolution, suitable for indoor rental activities that require high quality presentations, and its cost is lower than large indoor LED display;

Iron Cabinet LED Billboard Screen, Outdoor Waterproof Billboard P5 Epistar LED Chipset

Iron Cabinet LED Billboard Screen, Outdoor Waterproof Billboard P5 Epistar LED ChipsetIron Cabinet LED Billboard Screen, Outdoor Waterproof Billboard P5 Epistar LED ChipsetIron Cabinet LED Billboard Screen, Outdoor Waterproof Billboard P5 Epistar LED Chipset

Welcome to visit our website and inquire us more info,waiting for you all the time!!!

FAQ

1.Q:Are you a factory or trading company?

A:We are a factory,located in Dalang,Longhua District .

2.Q:What kind of payment terms you accept?

A:We accept T/T,Western Union,MoneyGram etc.

3.Q:What's packaging?

A:1.Flight case packaging

2.Wooden case packaging

3.36pcs in one case packaging

4.Customized packaging

4.Q:Does you have CE/ROHS certificates?

A:Yes, we offer the CE & ROHS certificates .

5.Q:What's the shipping method,shipping time?

A:Our products could be shipped by Sea, by Air, and by Express.

by sea:20-40days; by air:5-10days ;by express:3-6days
