SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
Specifications
Brand Name :
SCXK
Model Number :
SCXK-P8
Certification :
CE,ROHS ,FCC,UL
Place of Origin :
China
MOQ :
1sqm can be available
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
5-8days
Packaging Details :
the led display can be packaged with wooden box,paper box,flight case
Refresh Rate :
2500HZ/S
pixel density :
15625dots/sqm
cabinet size :
1024mm x 1024mm
Input Voltage :
AC220V/50H or AC110V/60H
Output Voltage :
DC5V,40A
Power Supply :
Series connection
Control method :
Synchronization & Asynchronization
Viewing Angle :
160°(Horizontal),110°(Vertical)
Display Colors :
R(1024) x G(1024) x B(1024)
Description

Made in china SMD3535 full color P8 8000cd LED Billboards MBI5124IC 3 years warrranty

Introduction

Shichuangxinke enjoys a global recognition with high-quality products, excellent sales services and well laid-out after-sales service, which is widespread throughout six continents. Shichuangxinke has LED video screens installed all over the world and plenty of representative cases can be found in Hong Kong, Marco, South Asia, Africa and America.

Quick details

1) Wide viewing angles
2) Seamless and lightweight
3) Dynamic scanning with truer, more stable pictures( no flickering)
4)Modular design for easy installation and maintenance
5) Consistent uniformity over time
6) Brilliant colors, breathtaking grayscales
7)Operating software compatible with widely available software
8) Remove the tools, improve the serviceability

SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty

Specification as follows

Type SMD3535(High Brightness LEDs)
LED Standard Real Pixel(1R1G1B)
Red Wavelength 625-630nm
Green Wavelength 515-530nm
Blue Wavelength 465-475nm
Pixel Pitch 5mm
Module Size 160mm x160mm
Module Resolution 64*64dots
Cabinet Size 640mmX640mm
Cabinet Resolution 256pixels *256pixels
Cabinets Material Sealed Iron Cabinet
Pixel Density 40000pixels/sq.m
Drive IC MBI5124
Power Supply Series connection
Brightness >7500cd/sqm
Display Color 16.7million
Viewing Angle 160°(Horizontal),110°(Vertical)
Best Viewing Distance 5m~200m
Max Power Consumption 600 w/sq.m
Average Power Consumption 300 w/sq.m
Weight 40kgs/sq.m
Refresh Rate 2500hz
Input Voltage AC220V/50H or AC110V/60H
Output Voltage DC5V,40A

SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty

We still have some other style led display.The parameter as follows.

the outdoor full color led display module ( smd and dip are available)
Number Drive mode Moduel size Resolution Led standard pixel density
P4 1/8 scan 256x128mm 64x32 3in1 62500
p4.81 1/13scan 250x250mm 52x52 3in1 43222
p5 1/8 scan 160x160mm 32x32 3in1 40000
P6 1/8 scan 192x192mm 32x32 3in1 27778
P8 1/4scan 256x128mm 32x16 3in1 15625
P10 1/4scan 160x160mm 16x16 3in1 10000
P12 1/4scan 192x192mm 16x16 3in1 6944
P16 static scan 256x256mm 16x16 3in1 3906
P20 static scan 320x160mm 16x8 3in1 2500
P25 static scan 200x200mm 8x8 3in1 1600
P31.25 static scan 250x250mm 8x8 3in1 1024
the indoor full color led display module( indoor usage only)
Number drive mode module size resolution led standard pixel density
p1.923 1/32scan 246x246mm 128x128 3 in 1 270420
p2 1/32scan 128x64mm 64x32 3 in 1 250000
p2.5 1/16scan 160x160mm 64x64 3 in 1 160000
p3 1/16scan 192x192mm 64x64 3 in 1 111111
p3.91 1/16scan 250x250mm 64x64 3 in 1 65410
p4 1/16scan 256x128mm 64x32 3 in 1 62500
p5 1/16/scan 320x160mm 64x32 3 in 1 40000
p6 1/16scan 384x192mm 64x32 3 in 1 27778
p7.62 1/8 scan 244x244mm 32x16 3 in 1 17222
p10 1/8 scan 320x160mm 32x16 3in 1 10000

Competitive advantage

1. We are led screen manufacturer for many years, quality is guaranteed

2. Because we are factory, our price is 5%-10% lower than middleman and trafficker at same level

3. Professional sales and technical team of 280 people to ensure perfect results

4. Customer requirements are fundamental, we make different solutions accroding different requirements of customers

SMD3535 Full Color P8 LED Display 8000cd LED Billboard 3 Years Warranty
