DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65
DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65
DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65
DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65
DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65
DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65
DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65
DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65
Specifications
Brand Name :
SCXK
Model Number :
SCXK-P12
Certification :
CE,RoHS,FCC,CCC,SAA,TUV,UL
Place of Origin :
China(Mainland)
MOQ :
Negotiations
Price :
Negotiations
Payment Terms :
T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability :
5000sqs/month
Delivery Time :
7-10 working days after payment
Packaging Details :
Wooden and flight cases,it's up to you.
Pitch :
12mm
Scan mode :
1/4
Control mode :
Synchronous by DVI
Certifications :
CE,RoHS,FCC,CCC,SAA,TUV,UL
Applations :
Dance floor,advertising shopping mall,airport,station,concert...
Module size :
192*192mm
Cabinet material :
Aluminum
Resolution :
16*16
Pixel density :
6944dots/sq
Brightness :
≥7500cd/sq
Warranty :
3-5 years
LED type :
DIP347
Working voltage :
DC5V
Indoor options :
P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P8,P10...
Description


P12 DIP Full Color Advertising LED Display 1/4 Scan 192*192mm Module IP65

Brand name
 SCXK-RGB LED Display
Inner Structure Material
Stainless steel, aluminum, galvanized sheet optional. Conventional aluminum profile.
Frame
Waterproof casing/Simple casing
Pixels
Available for customized. such P3, P3.91,P4,P4.81,P5, P6,P8, P10...
Pixel configuration
RGB, available for customized
The Packaging
Bubble Cotton & cardboard, Wooden boxes and flight cases for export.




Parameter Description

outdoor P12 LED Display
Resolution/mm 12
Pixel configuration 1R1G1B
Pixel density/pixels/m² 6944/square meter
Module resolution 16x16mm
Module size/mm 192*192mm
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Features:

1.First-class LED chip.Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness
2. High Contrast ratio: above 2000:1 .very high level to ensure a vivid image of our LED display screen system

3. Clear vivid image quality.more than 120 degree in horizontal and vertical to ensure you attract more audience to get short ROI of your LED display screen's investment
4. Long-term Brightness:use high quality led chip and lamp to ensure led display can last 11 years with low Lumens depreciation.
5.High definition. led display with high resolution to keep good video effect

DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65

DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65

DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65

DIP Large Full Color LED Display 12mm Pitch 1/4 Scan 192*192mm Module IP65

Advantage

1. High brightness: Due to the use of high brightness LED lights, viewers can see the image clearly from a distance under strong sunlight.

2. Long service life: The use of high quality LED lamps as the core material and the patented PCB design of the screen fundamentally guarantee the long service life of the product.
Long service life is fundamentally guaranteed.

3. Stable performance: special treatment for anti-electromagnetic waves, the screen adopts distributed scanning and modular design, stable performance.
Modular design, more reliable and stable work.

4. Delicate image: non-linear correction technology makes the image delicate and clear, and the video image is vivid and realistic.

5. Excellent flatness: The precision design of module frame components controls the deviation of adjacent modules within 0.1 mm, with excellent flatness and no mosaic phenomenon.

6. High Contrast: Consistent deep black and patented masking enable higher contrast and more vivid colors.

7. Easy Installation: Modular design makes installation and maintenance easier.

8. Excellent material: Adopting the same grade of imported LED chips from Taiwan, the United States or Japan, high-quality driver IC, low-noise power supply, which can ensure the screen to work smoothly in the environment of -40~60.

9. Multiple formats: Customers can choose any screen display format, can support TXT, graphics, pictures, animation and video programs.

10. Paint: Paint can protect PCB and related components from environmental erosion, with good resistance to high and low temperatures, as well as insulation, moisture, crepe, dust, corrosion and other excellent characteristics.

11. High anti-vibration performance: the cabinet must be tested for anti-vibration performance before shipment to avoid poor contact due to loose screws.
High anti-vibration performance: the cabinet must be tested for anti-vibration performance before shipment to avoid poor contact due to loose screws or disconnected cables after a long time of line transportation.

12. High waterproof performance: the cabinet must be waterproofed during the production process, and its front and back can be completely waterproof, so that it can work smoothly in outdoor all-weather.
