Specifications
Brand Name :
SCXK
Model Number :
P6
Certification :
CE/ROHS/FCC/ISO/UL
Place of Origin :
ShenZhen in China
MOQ :
1 sqm
Price :
negotiation
Payment Terms :
Western Union, MoneyGram, D/P, T/T, L/C
Supply Ability :
5000 sqm per month
Delivery Time :
7-10 working days after receive your payment
Packaging Details :
flight case, wooden case, carton, it is up to you.
Pixels :
6mm
Tube Chip Color :
Full color
Display Function :
Video
Cabinet :
Steel or Aluminum For Options
Frame Frequency :
>=60HZ
Average NO Failure :
>=1000hours
Transmiiting distance :
Internet cable <100m
Refresh Rate :
>=180HZ
Maximum power :
600m2
viewing angle :
80
optimal viewing distance :
>=4m
Description

Rental Led Display P6 P3 Die-casting Cabinet easy install 3 years warranty

1. With simple assembly/disassembly and compact packaging, it is extremely easy to transport, and saves time and labor.

2. deliver crystal clear images and are perfect to display high-definition images and videos for stage performances and television studios.

3.The die-cast aluminum casing is created with high-precision machining, ensuring complete panel flatness.

With a special connector design it is easy to reduce gaps while installing, creating a perfect display.

4. The use of a high-quality aluminum alloy with a fanless thermal design solves the heating problem, reduces noise and power consumption, and minimizes panel weight for easy installation

SCX-P6
Pixel pitch 6mm LED encapsulation SMD3528
Module resolution 32×32 dots View angle 140°/140°
Module size 192×192 mm Working environment
temp
Temp: -20°C to+60°C
Humidity: 35%~85%
Pixel density 27,778 dots/m² Working voltage 110 V±15%
or 230 V±15%
Pixel configuration 1R1G1B Driving method 1/8 scan,
constant current
Optimun Viewing
distance
>6 m Gray level RGB/8192/14bit
Max power
consumption
850 W/m² Display function Graphics,Animation,
and video
Brightness >2500 CD/m² Refresh rates > 800Hz
Life span >100,000 hours Blind spot rate < 0.00001

Outdoor Die casting Aluminum Rental SMD LED Display 640mm x 640mm

Pitch/mm P6 P6.67 P8 P10
Module size/mm 192x192 320x160 256x128 320x160
Density of pixel/(dots/m2) 27,778 22,478 15,625 10,000
Led encapsulation SMD 3535 SMD3535 SMD3535 SMD3535
Resolution of module 48X48 48X48 40X40 32X32
Optimum viewing distance 6-50m 7-75m 8-75m 10-150m
View angle / ° 160 H,120 V 160 H,120 V 160 H,120 V 160H,120V
Max power consumption/W/M2 1000 1100 1000 1000
Size of cabinet/mm 576x576 640X640 640X640 640X640
Resolution of cabinet 96x96 96x96 80x80 64x64
Weight of cabinet/kg 11 12 12 12
Driving method 1/8 scan constant current 1/8 scan constant current 1/4 scan constant current 1/4 scan constant current
Refresh rate Hz/S ≥2000 ≥2000 ≥2000 ≥2000
Luminance of white balance 8000 nits 7500 nits 7000 nits 6500 nits
Operation of Environmental Temperature/°C below 30 to above 50
Working vlotage 110-220 VAC/+/- 10%
Grey scale/color displaying colors≥16.7M(synchronized)
Brightness adjustment 256 levels of each color(manually),100 levels of each color(automatically)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system linsn(sending card,receiving cards and Hubs)
Average of non-failure life >50,00h
Life span >100,000h
Defect dot rate <0.0001

SMD Rental Led Display P6 Die-Casting Cabinet IP65 Waterproof For Indoor / OutdoorSMD Rental Led Display P6 Die-Casting Cabinet IP65 Waterproof For Indoor / Outdoor

Indoor and outdoor die-casting rental aluminum cabinet:

1) Lightweight
2) Seamless connection
3) Ultra thin
4) Easy to maintain
5) Easy to install

6) Noiseless
7) Ghost Cancelling
8) High refresh rate
9) Low brightness and high gray scale
10) Low power consumption

SMD Rental Led Display P6 Die-Casting Cabinet IP65 Waterproof For Indoor / Outdoor

Production process

SMD Rental Led Display P6 Die-Casting Cabinet IP65 Waterproof For Indoor / Outdoor

SMD Rental Led Display P6 Die-Casting Cabinet IP65 Waterproof For Indoor / OutdoorSMD Rental Led Display P6 Die-Casting Cabinet IP65 Waterproof For Indoor / Outdoor

SMD Rental Led Display P6 Die-Casting Cabinet IP65 Waterproof For Indoor / Outdoor

Free training:

3 days on-site complete technical training in our Shenzhen factory or internet on-line teamviewer via remote control or skype on line communication,what's more,we have valuable users' manual to guide for debugging and installing successfully.

Installation service:

The seller should provide on the spot installation instruction service for the buyer, including:
A, To check whether the bracket and frame are in conformity with the technical requirements of the structure scheme the seller provided
B, To instruct the buyer’s technicians to install the LED module cases and connection among those cases
C, To experiment and adjust the whole panel, examine and repair the defective devices, guarantee panel in secure operation.
D, To train the buyer’s technicians.
For spot installation and train in foreign country, the service is 100 usd/day, and the buyer must pay our technician’s living and traffic fee during the installation period.

4. MOQ:1PC

Our company information:

SCXK se ha especializado en campo del LED desde 2005. Somos un fabricante principal un abastecedor de la solución técnica del color lleno indoor un ledisplay al aire libre, exhibición LED del alquiler, módulos llevados donde en Shenzhen ctiy, provincia de Guangdong, China.
