High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
Specifications
Brand Name :
SCXK
Model Number :
SCXK-STP8
Certification :
CE ,rohs ,FCC ,UL
Place of Origin :
China
MOQ :
20sqm
Price :
negotation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000sqm/month
Delivery Time :
6-8days after your payment
Packaging Details :
the led display will be packaged with wooden box, flight case,
Material :
iron and steel
warranty :
3 years
led chip :
epistar
usage :
stadium outdoor usage
IP :
IP65
color :
full color
module size :
256mm x192mm
brightness :
7500cd/sqm
Description

High Resolution Stadium Led Display Full Color , 7500cd / Sqm High Definition Video Display

Our led display feature as follows.

1). Wide application field : Outdoor Commercial advertising LED display screen, LED display board for shopping mall,Stadium perimeter LED display ,bank&stock exchange LED display screen for rates showing,train & bus station LED display screen .
2). High brightness:7000cd/m2 Automatic or manual adjustment of the brightness of the display.
3).Top LED chip: Supplied by Silan of china & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display system.
4). Clear vivid image quality: Throughout the show, the picture clear, bright color.
5).Installation is simple,easy to use: Easy and simple installation interface and user friendly software to ensure that customers use easily.
High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
The parameter as follows:

The outdoor full color outdoor P8 stadium led display
LED LampsTypeSMD3535(High Brightness LEDs)
LED StandardReal Pixel(1R1G1B)
Red Wavelength625-630nm
Green Wavelength515-530nm
Blue Wavelength465-475nm
LED ModulePixel Pitch8mm
Module Size256mmx128mm
Module Resolution32*16dots
LED CabinetCabinet Size1024mmX1024mm
Cabinet Resolution128pixels *128pixels
Cabinets MaterialSealed Iron Cabinet
led screenPixel Density15625dots/sqm
Drive ICMBI5024
Power SupplySeries connection
Brightness>8500cd/sqm
Display Color16.7million
Viewing Angle160°(Horizontal),110°(Vertical)
Best Viewing Distance8m~200m
Max Power Consumption600 w/sq.m
Average Power Consumption 300 w/sq.m
Weight45kgs/sq.m
Refresh Rate3000hz
Input VoltageAC220V/50H or AC110V/60H
Output VoltageDC5V,40A
Grey Scale Levels16bit
Display ColorsR(1024) x G(1024) x B(1024)
MTBF10,000 hours


High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video DisplayHigh Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display


Our advantage as follow;
1.High and adjustable LED brightness can meet the demands of the changing requirement of customer in different environments.

2. No mosaic display due to excellent flatness and nice uniformity of light-emitting

3.Wide viewing angle and the horizontal angle can reach 120°m. The images display effect will not Change largely in the range.

4. Virtual pixel display screen can be adopted for outdoor displays to increase the resolution up to four times of real pixel, making the images softer and vivider

5. LED Single-lamp maintenance with low cost.

6. Good heat dissipation capability because of the unique design of vent fan.

7. Environmental-friendly and energy-saving.High Resolution Stadium Full Color LED Die-Cast Aluminum Screen , 7500cd/Sqm High Definition Video Display
