P5 Smd 2121 Rgb Led Display Full Color Module 320*120mm For Fasion
P5 Smd 2121 Rgb Led Display Full Color Module 320*120mm For Fasion
P5 Smd 2121 Rgb Led Display Full Color Module 320*120mm For Fasion
P5 Smd 2121 Rgb Led Display Full Color Module 320*120mm For Fasion
Specifications
Brand Name :
SCXK
Model Number :
P5
Certification :
CE/ROHS/FCC/ISO/UL
Place of Origin :
CHINA
MOQ :
1 sqm
Price :
negotiation
Payment Terms :
T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :
5000sqm per month
Delivery Time :
5-7 working days
Packaging Details :
flight case, plywood case, you choose what you like.
pitch :
5mm
pixel configuration :
1R1G1B
pixel density :
40000/m²
module size :
320*160mm
driving mode :
1/8 constant current
pixel :
64*32dots
tube chip color :
full color
Description

P5 Smd 2121 Rgb Led Display Full Color Module 320*120mm For Fasion

Product introduce:
1. LED display is the wide range of applications of high-tech display devices in recent years, with a high definition, stable quality, long life, flexible display function, it is very suitable for playing text, graphics, and multimedia festival.It even occupies an irreplaceable status in the outdoor area.
2. Full-color LED display can be used to broadcast news, entertainment information, commercials, video animation and a variety of media types, so as to achieve the effect of listen and watch to be together.
3. SCXK-P5 is a channel projects design, extensively applied to various projects and leasing ones, free to play video, graphic, image programs, and real-time, simultaneous and clear broadcast to disseminate various information.

Parameter:

P5 Indoor LED Display Technical Parameter (T=25℃)
Items Parameters Values
Basic Parameters Pixel Pitch 5mm
Pixel Configuration 1R1G1B
Physical Density 40000/m2
LED Encapsulation SMD2121
Module Size 320*160mm
Module Resolution 64*32dots
Steel Cabinet Size 960*960mm
Cabinet Resolution 128*128dots
Module Quantity / m2 19.53pcs / m2
Optical Parameters Equilibrium Brightness >1000cd/m2
Color Temperature 7500K—10000K
Viewing Angle 120°
Viewing Distance ≥5m
Performance Parameters Gray Scale / Color ≥16.7M color
Scanning Mode 1/16 scan
Frame Frequency ≥60Hz
Refresh Frequency ≥1920Hz
Driving Device MBI 5124 IC
Control Method Synchronous Control
Control System LINSN Control System
Operation Parameter Life Time >100000hours
Level of Protection IP40(Front), IP50(Back)
Working Environment Temperature -10℃ ~ 60℃
Working Environment Humidity 10% ~ 70% RH
Storage Temperature Range -10℃ ~ 60℃
Electric Parameter Module Working Voltage DC 4.2V - DC 5V
Power Supply Requirement 100-220 Va.c±10%, 50 Hz±4%
Module Consumption 20W
Screen Consumption 700W/m2

Feature

1. Multi Line Displays' Application are Endless

2. Up-dated Multi Line LED Electronic Displays are Easy to use and Up-dated quickly With no technical expertise

3.Available in a variety of character heights

4.LED Colour selectable,we have RED, GREEN, YELLOW, BLUE ,WHITE and RGB, BI-Color are also available.

5. The signs can run at Various speed and Characters including Bold, Run Left/Right etc

6.Can be controlled remotely , like WIFI, GSM, GPRS,3G,4G,5G

Why choose us
Continues Quality
With more than 10 years experience in led display,equipments are updated regularly.What’s more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built effective modular production.We always stick to promote the technical innovation and reduce cost to benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to you.
After-sales:We will track the products usage and then constantly perfect our products.


Company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
P5 Smd 2121 Rgb Led Display Full Color Module 320*120mm For Fasion


Certificate
P5 Smd 2121 Rgb Led Display Full Color Module 320*120mm For Fasion


Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
